Summary of Contents for Heyer AGFS

  • Page 1 Operating Instructions Anaesthetic Gas Evacuation System AGFS...
  • Page 2: Table Of Contents

     Operating Instructions AGFS  1. Manufacturer's information ............... 3 2. Foreword..................... 4 3. Function and mode of operation..............5 4. Assembly dimensions and parts specification..........6 Front view with front plate....................6 Front view without front plate.....................7 Side view...........................7 Hose plan..........................9 5.
  • Page 3: Manufacturer's Information

     Operating Instructions AGFS  1. Manufacturer's information Product Anaesthetic Gas Evacuation System AGFS Manufacturer and Distributor Heyer Aerotech GmbH Nieverner Straße 30 56132 Nievern Tel.: (0 26 03) 20 04 Fax.: (0 26 03) 40 20 E-Mail: office@heyer-aerotech.de...
  • Page 4: Foreword

    The anaesthetic gas evacuation system AGFS is in accordance with all standards and specifications that currently apply to the production and operation of this product.
  • Page 5: Function And Mode Of Operation

    This is avoided by installing an anaesthetic gas evacuation system. The anaesthetic gas evacuation system AGFS is installed in the vicinity of the anaesthesia working area. A transvector integrated in the AGFS generates the required underpressure. The suction power is adjusted separately on every evacuation box to a standard value of 45-50 l/min, but it can be tailored to the customer's needs.
  • Page 6: Assembly Dimensions And Parts Specification

     Operating Instructions AGFS  4. Assembly dimensions and parts specification 4.1 Front view with front plate Fig. 1 Front view with front plate Legend: 1 Front plate 3 Visual signal 2 Connection AGFS gas suction plug...
  • Page 7: Front View Without Front Plate

     Operating Instructions AGFS  4.2 Front view without front plate Fig. 2 Front view without front plate Legend: 4 Bend 15 5001A 7 VACUFLEX hose 5 Hose clip 8 Flush socket AGFS 6 Connection AGFS suction plug 9 Transvector complete...
  • Page 8: Side View

     Operating Instructions AGFS  4.3 Side view Fig. 3 Side view Legend: 10 O-ring 14 x 1 16 Valve housing AGFS 11 Valve disk 17 Seat valve 12 Spring for valve disk 18 O-ring 7 x 1,5 13 O-ring...
  • Page 9: Hose Plan

     Operating Instructions AGFS  4.4 Hose plan Fig. 4 View of hose plan Legend: 20 PE hose 150 mm 23 Choke valve 21 PE hose 150 mm 24 Swing fixture 22 PE hose 240 mm...
  • Page 10  Operating Instructions AGFS ...
  • Page 11: Technical Data

     Operating Instructions AGFS  5. Technical data Performance: Suction power: 45-50 l/min Air consumption: 40-60 l/min maximum Suction volume: 80 l/min maximum Connections: Compressed air: Copper pipe 8 x 1 mm Exhaust air: Copper pipe 15 x 1 mm...
  • Page 12: List Of Spare Parts

     Operating Instructions AGFS  6. List of spare parts Pos. Order number Description Front plate AGFS 117-1955 Connection AGFS plug Green visual signal 117-1440 Bend 15 5001A 131-1810 Hose clip 046-4080 Cap screw (Allen) 047-4102 VACUFLEX hose 006-3900 Flush socket AGFS...
  • Page 13: Warranty

    4. These guarantee conditions are invalidated in the case of third-party intervention, modification and/or repair of the product by persons not authorised by HEYER Aerotech, or if the product is operated with auxiliary equipment or spare parts of from another source.
