with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la
conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et
la conformité de rf.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
This equipment should be installed and operated with a minimum distance of 20 centimeters between the
radiator and your body.
Cet émetteur ne doit pas tre Co-placé ou ne fonctionnant en même temps qu'aucune autre antenne ou
émetteur. Cet équipement devrait être installé et actionné avec une distance minimum de 20 centimètres
entre le radiateur et votre corps.
Class B Notice for Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
3. For EU - CE compliance
This device complies with the EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC.
Note: Shielded Ethernet cable must be used in order to comply with emission limits.
4. Safety notice
a) This device is to be used with Certified Power adaptor with output rated at 5VDC, 2A. Power adapter
b) Power adapter must meet local safety standards and requirements based on product intended use.
c) Power adapter must meet Operating environment conditions as specified in section 4 above.
d) Maximum allowed current consumption of the device is 2A, including external USB devices (each can
e) This device does not ship with a battery. Safety testing was made without an RTC backup battery.
f) Careful testing and measurement of component temperature must be made when enclosing the
i)
5. Disposal
Follow local regulations regarding disposal of the product. Dispose of your product in accordance with local
regulations. In some areas, the disposal of these items in household or business trash may be prohibited.
Help us protect the environment - recycle!

COPYRIGHT NOTICE

Copyright © 2014
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
must meet Limited power source (LPS) requirements.
consume up to 0.5A based on USB 2.0 standard.) As an open and configurable platform, the user must
check any configuration they build to not exceed the allowed current consumption limits.
HummingBoard models with add-ons such as RTC battery, PCIe add-on, mSATA add-on or USB devices
connected to internal USB ports. RTC Backup Batteries have critical safety parameters such as
temperature range and current rating that must NOT be exceeded. RTC circuit is included in figure 3
for reference.
g) When installing RTC Backup battery, check for: Compatibility with NXP's PCF8523 specifications.
Positive pin of battery is connected to pin 1 of the RTC Backup Battery connector (see figure 2).
Battery's actual worst case temperature and withdraw current meet battery specification.
h) Caution, Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries
according to the local regulations.
Some surfaces of the device might reach high temperature when the device is under heavy work load.
See figure 2, page 3
