ATTACHING SPACERS

1
Insert the gauge into the gap between the front and back
panel doors.
3
Secure the spacer to the latch using the two included
screws.
www.mobiletechinc.com | T:800.426.6844
MTI PLUNGER LOCKS™ PRODUCT MANUAL
2
The letter closest to the edge behind the front panel
indicates the spacer required to fill the gap. "A" does not
require an additional spacer.
4
Apply adhesive to the back of the spacer or to the back
of the latch if the spacer is not used.
MTI P/N 063-00259 rev A ©2019 MTI All Rights Reserved
OR
