PLUNGER LOCK PARTS
Plunger
Lock Body
Mounting
Template A
Latch Spacer D
www.mobiletechinc.com | T:800.426.6844
Battery installation on page 8.
MTI PLUNGER LOCKS™ PRODUCT MANUAL
Battery
Mounting
Template B
Latch Spacer E
Keys not included. See Page 4.
Latch
Latch VHB
Latch Spacer Screws
Latch Spacer F
MTI P/N 063-00259 rev A ©2019 MTI All Rights Reserved
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MTI Plunger Lock
Summary of Contents for MTI Plunger Lock
- Page 1 Battery Latch VHB Mounting Mounting Template A Template B Latch Spacer Screws Latch Spacer D Latch Spacer E Latch Spacer F Keys not included. See Page 4. www.mobiletechinc.com | T:800.426.6844 MTI P/N 063-00259 rev A ©2019 MTI All Rights Reserved...
- Page 2 Lock will emit a double beep, confirming the key whitelist is cleared. It will stop ticking after 10 seconds and resume normal operation if the Authorization Card is not swiped again. www.mobiletechinc.com | T:800.426.6844 MTI P/N 063-00259 rev A ©2019 MTI All Rights Reserved...
- Page 3 To use the MTI Connect Business Intelligence feature of your MTI locks you must have an internet connection, a MTI Connect Hub to create the mesh network, and the MTI Connect Card, which allows you to convert modes. In Connect mode, the lock will check in with the Hub every hour, and every time a lock is accessed.
- Page 4 Secure the spacer to the latch using the two included Apply adhesive to the back of the spacer or to the back screws. of the latch if the spacer is not used. www.mobiletechinc.com | T:800.426.6844 MTI P/N 063-00259 rev A ©2019 MTI All Rights Reserved...
- Page 5 Open the sliding doors to fully expose the latch template, Peel the backing off the VHB on the latch. which will aid in placement. www.mobiletechinc.com | T:800.426.6844 MTI P/N 063-00259 rev A ©2019 MTI All Rights Reserved...
- Page 6 Remove Template B. Note: Make sure keys have been programmed to lock prior to this step. www.mobiletechinc.com | T:800.426.6844 MTI P/N 063-00259 rev A ©2019 MTI All Rights Reserved...
- Page 7 Technical Data Operating frequency 125KHz , 2.4GHz : 2405- 2480MHz Operating temperature: 0º C to 40º C Max power : 125KHz <42dBuA/m at 10m, 2.4GHz < 20 dBm www.mobiletechinc.com | T:800.426.6844 MTI P/N 063-00259 rev A ©2019 MTI All Rights Reserved...
- Page 8 EU. To prevent harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To dispose of used devices contact MTI Global Services Contact Center at 503-648-6500 or contact local recycling company for proper recycling instructions for electronic devices.
