Introduction; Introducing Xpress Xl - Microtech Xpress XL Hardware Manual

Introduction

Introducing Xpress XL

This section will provide all the information you need to unpack, install, configure
and use this system.
Xpress XL Parts
The following section shows and identifies all the important parts of your Xpress
XL. These components will be referred to later in the manual; take a few moments to
become familiar with them.
The main parts of the Xpress XL production system are indicated below (front view).
Hoist
Arm
Elevator
Printer 2
6 Disc Writers
Reject Spindle (R)
Spindle #5
Spindle #4
Spindle #3
Spindle #2
Spindle #1
Spindle (L)
Switch Panel
Camera Support
Boom
Disc
Readers
Digital Camera
2
(ImageAligner )
Light Shield/
Camera Mount
Printer 1
Printer Plate
6 Disc Writers
Drive Encosure
Handholds
Base Unit/
PC Enclosure
