Microtech Xpress XL Hardware Manual page 14

K2 Printer - Right Side
1. Connect parallel cable between port on back of printer and port on back of Xpress
2. Connect serial control cable between port on back of printer and port on back of
3. Connect printer power cord to port on back of printer, plug into standard electri-
K2 Printer - Left Side
1. Connect USB Cable between port on back of Printer and port on back of Xpress
2. Connect serial control cable between port on back of printer and port on back of
3. Connect printer power cord to port on back of printer, plug into standard electri-
Installing Software Key
1. Install Software Key into any open port on back of Xpress XL Base Unit.
Installing ImageAligner Option
1. Place Camera Support Boom on top of Printer Base Plate behind Elevator.
2. Tighten attached knobs (3) to secure Camera Support Boom to threaded holes in
3. Line up pegs (2) and threaded rod on top of Light Shield/Camera Mount Disk
4. Finger tighten knob onto threaded rod to secure Light Shield/Camera Mount
5. Attach Camera to Mount by finger tightening attached thumbscrew.
6. Connect camera Cable between port on side of Camera and USB port on back of
7. Secure camera cable to Camera Support Boom using attached cord clips
8. Repeat procedure for 2nd camera.
Additional Cables
1. Connect Xpress XL main power cord to port on back of base unit, plug into
2. Connect serial cable from COM2 on back of base unit to Host COMM on back of
10
XL Base Unit.
drive enclosure (marked printer right).
cal outlet.
XL Base Unit.
drive enclosure (marked printer left).
cal outlet.
PRINTERS ARE READY FOR INITIAL TESTING
Printer Base Plate.
with holes on bottom of camera support boom.
Disk to Camera Support Boom.
Xpress XL base unit.
PRINTERS ARE READY FOR INITIAL TESTING
standard 110v electrical outlet. Connect power cord for drive enclosure power
supply into standard 110v electrical outlet.
drive enclosure.
XPRESS XL IS READY FOR INITIAL TESTING
