- Page 1 Atlantis Shower System Model #1059-BN, 1059-CH, 1059-MB, 1059-ORB PW-91059-8018BRN, PW-91059-8018CP, PW-91059-8018BM, PW-91059-8018BRZ PW-91059-8025BRN, PW-91059-8025CP, PW-91059-8025BM, PW-91059-8025BRZ Owner's Manual...
- Page 2 Atlantis Shower System Please Read The Following Instructions COMPLETELY Before Beginning! Our goal is to ensure your installation goes smoothly and safely. Please read these instructions carefully and follow recommendations for plumbing and mounting. After reading instructions, if you determine you do not have the necessary skills and/or tools, we recommend that a licensed plumbing contractor complete the installation.
- Page 3 Parts Legend 1. Showerhead 7. Fitting 13. Wand 2. Washer.......(3) 8. Diverter Mount 14. Wand Holder 3. Shower Arm 9. Inlet Fitting 15. Hose 4. Shower Riser 10. Top-T 16. Diverter 5. O-Ring......(2) 11. Shower Pipe 17. Set Screw.....(2) 6. Escutcheon....(2) 12.
- Page 4 Installation Instructions BEFORE YOU BEGIN Measure the following to ensure your Shower System will fit properly. New Construction Retrofit 9” minimum 28” minimum 28” minimum Make sure distance from water outlet and Remove existing shower arm and shower head. mixing valve trim (NOT INCLUDED) is a Make sure distance from water outlet and minimum 28"...
- Page 5 Installation Instructions Step 1 Step 3 Step 2 Secure shower bar to fitting and secure with set screws. [Step 1] Apply a generous amount of PTFE (plumber's) tape to end of end of inlet fitting (9). [Step 2] Insert inlet fitting into existing plumbing which old shower arm was screwed into.
- Page 6 Installation Instructions CAUTION: Live Plumbing Glue Handshower holder is tapered. Assure larger Tape opening is upright. Back of handheld holder Place lower mount plate (8) on marked location and Apply glue to the handshower holder (14) as indicated mark holes. (1 screw should be on the left side and and add tape (included) to secure onto wall.
- Page 7 Installation Instructions With Optional Grab Bar Optional grab bar sold separately on Product Fully Assembled www.PulseShowerSpas.com...
- Page 8 Ch e m i c a l s O r A b r a s i ve s ! MANUFACTURER'S LIFETIME LIMITED WARRANTY 1. Defects Covered; Warranty Period: Pulse Shower Spas, 5. No Other Warranties; Limitation of Liability: OTHER Inc. (“Pulse”) warrants to the original consumer purchaser THAN THE LIFETIME LIMITED WARRANTY STATED who purchases this shower spa (the “Product”) for use in...
