- Page 1 Monterey ShowerSpa Model #1042-SSB Owner’s Manual...
- Page 2 Monterey ShowerSpa Model 1042-SSB Please Read The Following Instructions COMPLETELY Before Beginning! Our goal is to ensure your installation goes smoothly and safely. Please read these instructions carefully and follow recommendations for plumbing and mounting. After reading instructions, if you determine you do not have the necessary skills and/or tools, we recommend a licensed plumbing contractor complete the installa- tion.
- Page 3 Product Dimensions 2.75” 7.87”...
- Page 4 Parts Legend Name Quantity ShowerSpa body Shower arm Escutcheon Silicone gasket Rubber washer 90° elbow/Supply line Shower head Screw Mounting bracket Wall anchor Hand shower holder Hand shower hose Hand shower...
- Page 5 Assembly After unpacking your ShowerSpa, some assembly is required prior to installation. Shower Arm Assembly 1. Place escutcheon (3) over threaded end of shower arm (2) and insert through shower arm hole. At back of panel, place silicone gasket (4) over shower arm and secure with nut (5) to ShowerSpa.
- Page 6 Retrofit – Existing Shower Replacement NOTE—In a remodel in which you are not replacing the finished wall surface (tile, or backing material) it is advisable to purchase a PULSE ShowerSpa model that covers the location of your existing valve assembly—either single handle or two-handle type. If your PULSE ShowerSpa model does not cover this area, you will need to either choose another PULSE ShowerSpa model that does or make necessary repairs with appropriate materials (i.e.
- Page 7 Usage Pressure Balance Mixing Valve The Monterey ShowerSpa is equipped with a cUPC® pressure balance mixing valve to adjust water flow and temperature. The valve automatically adjusts to changes in water pressure (i.e. someone flushes a toilet), keep- ing your temperature constant and preventing accidental scalding. To turn on the ShowerSpa simply raise the handle until the desired flow rate is achieved.
- Page 8 Manufacturer’s Limited Warranty PULSE ShowerSpas, Inc. warrants that all ShowerSpas are free from Proof of purchase (original sales receipt) must be provided to PULSE defect in workmanship and/or materials for a period of three years ShowerSpas, Inc. with all warranty claims. from the date of purchase.
