Troubleshooting

No picture
The signal cable should be completely connected to the display card/computer.
The display card should be completely seated in its slot.
The monitor does not support DisplayPort converter adapter.
Front Power Switch and computer power switch should be in the ON position.
Check to make sure that a supported mode has been selected on the display card or system being used. (Please consult
display card or system manual to change graphics mode.)
Check the monitor and your display card with respect to compatibility and recommended settings.
Check the signal cable connector for bent or pushed-in pins.
Check the signal input.
Power key does not respond
Unplug the power cord of the monitor from the AC outlet to turn off and reset the monitor.
When something is stuck on the bezel, key becomes unresponsive.
Image persistence
Image persistence is when a "ghost" of an image remains on the screen even after the monitor has been turned off. Unlike CRT
monitors, LCD monitors' image persistence is not permanent, but constant images being displayed for a long period of time
should be avoided.
To alleviate image persistence, turn the monitor off for as long as an image was displayed. For example, if an image was on the
monitor for one hour and a residual image remains, the monitor should be turned off for one hour to erase the image.
NOTE:
As with all personal display devices, NEC DISPLAY SOLUTIONS recommends using a screen saver at regular intervals
whenever the screen is idle or turning off the monitor when not in use.
Message "OUT OF RANGE" is displayed (screen is either blank or shows rough images only)
Image is displayed only roughly (pixels are missing) and OSD warning "OUT OF RANGE" is displayed: Either signal clock or
resolution is too high. Choose one of the supported modes.
OSD warning "OUT OF RANGE" is displayed on a blank screen: Signal frequency is out of range. Choose one of the supported
modes.
Image is unstable, unfocused or swimming is apparent
Signal cable should be completely attached to the computer.
Disconnect the DP cable and touch "SELECT" key, and then adjust the OSD value using the "-" or "+" key.
Use the OSD Image Adjust controls to focus and adjust display by increasing or decreasing the fine total. When the display
mode is changed, the OSD Image Adjust settings may need to be re-adjusted.
Check the monitor and your display card with respect to compatibility and recommended signal timings.
If your text is garbled, change the video mode to non-interlace and use 60 Hz refresh rate.
Picture is not as bright
Make sure ECO MODE is turned off.
Signal cable should be completely attached.
LCD brightness degradation occurs due to long-term usage or extreme cold conditions.
If the brightness fluctuates, make sure DV MODE is set to OFF.
LED on monitor is not lit (no blue or amber color can be seen)
Power Switch should be in the ON position and power cord should be connected.
Display image is not sized properly
Use the OSD Image Adjust controls to increase or decrease the H.SIZE.
Check to make sure that a supported mode has been selected on the display card or system being used.
(Please consult display card or system manual to change graphics mode.)
No Video
If no video is present on the screen, turn the Power key off and on again.
Make certain the computer is not in a power-saving mode (touch the keyboard or mouse).
Some display cards do not output video signal when monitor is turned OFF/ON or disconnect/connect from the AC power cord
under low resolution with DisplayPort.
No Sound (E233WMi)
Check to see if speaker cable is properly connected.
Check to see if mute is activated.
Check the volume in the OSD menu.
Check selected OSD's Tools "SOUND INPUT", when DisplayPort is in use.
Brightness variations over time
Change DV MODE to OFF and adjust brightness.
NOTE:
When DV MODE is set to ON, the monitor automatically adjusts brightness.
English-19
