Specifications - E233WMi

Monitor Specifications
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
DisplayPort:
DisplayPort Connector:
DVI:
DVI-D 24pin:
VGA:
15pin Mini D-sub:
Display Colors
Synchronization Range
Viewing Angle
Resolutions Supported (Some systems may
not support all modes listed).
Active Display Area
Landscape: Horiz.:
Portrait: Horiz.:
AUDIO
AUDIO Input:
STEREO Mini Jack:
DisplayPort Connector:
Headphone Output: STEREO Mini Jack:
Speakers
Practical Audio Output:
Power Supply
Current Rating
Dimensions
Height Adjustment:
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and
necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on the screen is actually one
pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE:
Technical specifications are subject to change without notice.
MultiSync E233WMi Monitor
Diagonal:
58.42 cm/23 inches
58.42 cm/23 inches
1920 x 1080
Digital RGB
Digital RGB
Analog RGB
Sync
16,777,216
Horizontal:
31.5 kHz to 81.1 kHz
Vertical:
56 Hz to 75 Hz
Left/Right:
±89° (CR > 10)
Up/Down:
±89° (CR > 10)
720 x 400*
VGA text
1
640 x 480*
1
at 60 Hz to 75 Hz
800 x 600*
at 56 Hz to 75 Hz
1
832 x 624*
at 75 Hz
1
1024 x 768*
at 60 Hz to 75 Hz
1
1152 x 870*
at 75 Hz
1
1280 x 960*
1
at 60 Hz
1280 x 1024*
at 60 Hz to 75 Hz
1
1440 x 900*
at 60 Hz
1
1680 x 1050*
1
at 60 Hz
1920 x 1080 at 60 Hz........................................... NEC DISPLAY SOLUTIONS cites recommended
509.2 mm/20.0 inches
Vert.:
286.4 mm/11.3 inches
286.4 mm/11.3 inches
Vert.:
509.2 mm/20.0 inches
Analog Audio
Digital Audio
1.0 W + 1.0 W
AC 100 - 240 V, 50/60 Hz
0.55 - 0.30 A
Landscape:
544.3 mm (W) x 374.5 - 484.5 mm (H) x 213.9 mm (D)
21.4 inches (W) x 14.7 - 19.1 inches (H) x 8.4 inches (D)
Portrait:
322.2 mm (W) x 560.8 - 595.6 mm (H) x 213.9 mm (D)
12.7 inches (W) x 22.1 - 23.4 inches (H) x 8.4 inches (D)
110 mm / 4.3 inches (Landscape orientation)
34.8 mm / 1.4 inches (Portrait orientation)
5.7 kg (12.6 lbs) (with stand)
5°C to 35°C/41°F to 95°F
Humidity:
20% to 80%
Altitude:
0 to 6,562 Feet/0 to 2,000 m
-10°C to 60°C/14°F to 140°F
Humidity:
10% to 85%
Altitude:
0 to 40,000 Feet/0 to 12,192 m
Notes
Active matrix; thin film transistor (TFT) liquid crystal
display (LCD); 0.265 mm dot pitch; 250 cd/m
luminance; 1000:1 contrast ratio (typical), (5000:1
Contrast ratio, DV MODE ON).
DisplayPort Complies with Standard V1.1a,
applicable to HDCP
DVI (HDCP)
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Depends on display card used.
Automatically
Automatically
resolution for optimal display performance.
Stereo L/R 1.0 Vrms 20 Kohm
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Impedance 32 Ohm
English-17
white
