USB INTERFACE
12.5 UPDATE LLXXX (MAIN RELAY PCB) SOFTWARE FROM USB FLASH DRIVE
Press [UP] or [DOWN] button to select "6:Update LLXXX" and press [ENTER] button.
Press [UP] or [DOWN] button to select software file and press [ENTER] button to confirm. Press [ESC] button to cancel.
Note: The file path of llxxx software on the USB FLASH DRIVE should be: "H:\LLXXX\IPSP\PROGRAM".
After the software has been downloaded completely, please restart the controller.
12.6 COPY PUNP VFD PARAMETER FROM USB FLASH DRIVE TO WASHER
Press [UP] or [DOWN] button to select "7:VFDParaFromUSB" and press [ENTER] button.
Press [ENTER] button to confirm. This operation will upload all of the parameters of PUNP VFD from USB FLASH DRIVE to
controller.
Press [ESC] button to cancel.
Note: The file path of parameter on U stick should be: "H:\LDXXX\PARAMETER".
The VFD installed on the machine should be made by PUNP and the parameter VFD type should be set as "PUNP".
12.7 COPY VFD PARAMETERS FROM WASHER TO USB FLASH DRIVE
Press [UP] or [DOWN] button to select "8:InvtParaToUSB" and press [ENTER] button.
Press [ENTER] button to confirm. This operation will download all of the parameters of PUNP VFD from controller to U stick.
Press [ESC] button to cancel.
40
Part. 14000002 Rev. 06//2021
6:Update LLXXX
X1LL019AX16001-1.V100A0
X1LL019AX16001-1.V100A1
<Enter>=Confirm
6:Update LLXXX
X1LL019AX16001-1.
Waiting... 05%
WelcometoUSB
7:InvParaFromUSB
<Enter>=Confirm
WelcometoUSB
8:InvtParaToUSB
<Enter>=Confirm
6:Update LLXXX
X1LL019AX16001-1.
Success, restart!
