WASH CYCLE PROGRAMING

10.0 PROGRAMMING THE WASHER
The washer comes pre-programmed with standard wash programs. These programs have been optimized for cleaning,
gentleness and wash cycle time. If neccessary, these programs can be edited to meet a specific application.
Esc Enter
Note: the key function as shown in the figure.
The hot, warm, cold and start buttons are used to navigate the washer menus.
Hot - Up Arrow
Warm - Down Arrow
Cold - Escape
Start - Enter
10.1 ENTERING PROGRAMMING MODE
On initial power up, the machine is in countdown mode for 10 seconds. During the countdown, press [Up]+[Down] to enter the
Functions menu. Then select "Edit Program", and press the key [Enter] to enter the program interface and input the password
to enter the Edit Program interface. The default password is ↑ ↓ ↑ ↓ ↓ ↑ ↓ ↑ (hot warm hot warm hot warm hot warm) (1 2 1 2
1 2 1 2)
Then select your desired program by pressing [Up] or [Down] button.
34
Part. 14000002 Rev. 06//2021
PROGRAMMABLE CYCLES
Ciclos Programables
1 2 3
Function Menu
Edit Program
Statistics
<Esc>3S=Quit
Edit
Hot
<Esc> = Quit
INSTRUCTIONS
Instrucciones
Load items in washer and close door
1
Cargue los artículos en la lavadora y cierre la puerta
Select wash cycle
2
Seleccione el ciclo de lavado
Press start button
3
Presione el botón de arranque
START
Arranque
