X. Specifications
Engine Torch Plug #
R100
Model
L×W×H
Dry Weight
Gasoline Engine Type
Displacement
Starter
Compression Ratio
Bore × Stroke
Maximum Output Power
Maximum Torque
Cooling System
Ignition System
Spark Plug
Spark Plug Clearance
Lubrication System
Lubrication Type
Oil Volume
Fuel Volume
Air Filter
Speed
Choke
PTO Shaft Rotation
Recommended Spark Plugs
Bosch Plug #
E4RC WR10A WR10AC W14FR-U W14FR-L
R100 (99cc)
12.2"x11.4"x12.2" (310×290×310mm)
22 lb (10kg)
4-Stroke, OHV, Single Cylinder,
Horizontal Shaft
99cc
Manual Recoil
8.3:1
56×40mm
1.8kW @ 3,600 rpm
4.7N·m @ 2,500 rpm
Forced Air-cooled
Transistorized Magneto Ignition (TCI)
See Table Below
.028"x.032" (0.7- 0.8mm)
Forced Splash
SAE15-40
.37 qt/11.8 oz. (0.35L)
.53 gal/2.1 qt. (2L)
Foam
Manual Control
Manual Control
Counterclockwise
Denso Plug #
