Troubleshooting

Symptom Possible Cause
Keyboard / Mouse
needs to be reset.
Keyboard
Hotkey sequence
and/or
input incorrectly.
Mouse Not
Responding
Switch needs to be
reset.
Resolution and/or
Video
Refresh rate set too
Problems
high.

Specifications

Function
Computer Connections
Port Selection
Console
Ports
Connectors
KVM
Ports
LEDs Selected
Cable
Computers
Length
Emulation Keyboard/ Mouse
Video
Scan Interval
Operating Temp.
Environment
Storage Temp.
Humidity
Housing
Physical
Weight
Properties
Dimensions
(L x W x H)
Unplug the keyboard / mouse from the Console
Keyboard Port, then plug it back in.
Resend the Hotkey command - press and
release each key in the sequence individually.
Turn off the computers; wait 5 seconds; turn the
computers back on.
Select a lower resolution and/or bandwidth.
2
Hotkey
Keyboard 1 x USB Type A Female (Black)
Video 1 x HDB-15 Female (Blue)
Mouse 1 x USB Type A Female (Black)
Keyboard/ Mouse 2 x USB Type A Male (Black)
2 x HDB-15 Male (Blue)
Video
2 (Green)
1.2m
USB
2048 x 1536; DDC2B
3, 5, 10, 20 Seconds
0-50°C
-20-60°C
0-80% RH, Non-condensing
Plastic
0.31 kg
7.90 x 7.90 x 2.50 cm
4
Action
ENKVM-USB
