- Page 1 Caledonia Rattan Bedside Table A S S E M B LY G U I D E...
- Page 2 F O R Y O U R S A F E T Y Lift, don’t drag. This protects Check the assembly guide your floor and product. for required components. Assembly requires 2 people. Assembling this product on It's always easier with a a soft surface protects its friend.
- Page 3 Components Before you get started, check you have all of the pieces below. If anything’s missing, we’ll sort it out right away. Simply visit: www.brosa.com.au/pages/product-return-and-parts-request ① Body x 1 ③ Shelf x 1 ② Leg Frame x 2 Hardware x 12...
- Page 4 Step 1 ③ Fit the tongues of the shelf into the slots of the leg frames ②. Make sure the stickers match as per the diagram below. ③ ② ②...
- Page 5 Step 2 Fit a spring washer to a long bolt followed by a flat washer C. Insert the long bolt into a hole on the leg frame to fix the shelf. Screw the bolt with your hand. Leave the bolt loosely attached. Repeat this for the remaining holes on the leg frames.
- Page 6 Step 3 Align the structure formed in Step 2 with the holes on the bottom of the body ①. Make sure the stickers match as per the diagram below. Fit a flat washer to a short bolt A. Insert the bolt into a hole on the leg frame.
- Page 7 Step 4 Once the structure is built up, tighten all bolts with the Allen key E.
- Page 8 Step 5 Place the completed piece of furniture the right way up in its desired location. Adjust the foot stoppers to make all legs sit firmly on the ground.
- Page 9 Step 6 Enjoy your new Caledonia Rattan Bedside Table!
-
Page 10: Troubleshooting
Troubleshooting 1. Follow the steps below to detach the drawer if needed. Step 1 Pull the drawer until the levers of the drawer slides come out as shown in the zoomed-in diagram below. - Page 11 Step 2 Press down on the lever on one side and up on the opposite side to disengage the mechanism. Pull the drawer out while pressing the levers.
- Page 12 2. Follow the step below to attach your drawer again. Step 1 Line up the slides and push until you hear the “click” indicating that slides have reengaged.
- Page 13 Assembly 1. Assemble furniture using our Assembly Guides. You can find them at support.brosa.com 2. Do not dispose of any packaging or contents of the shipping carton until assembly is completed to avoid accidentally discarding small parts or hardware.
- Page 14 7. Use protective coasters and mats for hot items on the furniture. 8. Keep furniture away from intense direct sunlight. Exposure can cause cracks or discolouration. 9. Severe changes in temperature and humidity can accelerate ageing. Keep furniture at least 60cm from heating or air conditioning. 10.
