  • Page 2 Thank you for purchasing this C230 portable media player, which delivers acombination of style, features and user friendliness, the best combination that you can find nowhere else – a new experience of powerful, yet intuitive control over you audio and video collection.
  • Page 3 This product is not sponsored, endorsed or approved by Microsof Warning: C230 is a precision device made of sensitive components. Some safety precautions and guidelines must be followed. To avoid damage, make sure that you do not drop, smash o r mis-use the device.

  • Page 4: Safety Precaution

    SAFETY PRECAUTION Warning: C230 is a precision device made of sensitive components. Some safety precautions and guidelines must be followed. Do not place heavy objects on the device. Keep away from harsh environments including humid dusty and smoky areas. Do not clean with chemical or detergent.
  • Page 5 Do not dry the product with heater or microwave. Do not use headphone/ earphone while cycling, driving, or operating any motorized vehicle. Reduce volume or stop using the player if you experience a ringing in your ears. Reduce volume while walking especially at pedestrian crosswalk.

  • Page 7: Description Of Lcd Display

    DESCRIPTION OF LCD DISPLAY Locked Number of song being played / total number of songs Song name Album name Status icon PACKING LIST Main Unit Earphone Note: Please keep all the packing materials for future reference or transportation. Current mode Playing progress bar User Manual SD card...

  • Page 8: Battery Charging

    BATTERY CHARGING Charge the battery using the supplied USB2.0 cable. When connecting the device to PC via USB cable and it will start charging automatically. And it will take about 4 hours to charge the device fully. Note : THE COMPUTER MUST BE ON TO CHARGE THE PLAYER CORRECTLY. Note: 1.
  • Page 9 RESET If the device freezes and has no response when operating, please shut down the device and turn it on again in 15 seconds, or insert a clip into the reset hole under the plastic cover of USB2.0 port. MINIMUM PC SYSTEM REQUIREMENT You can connect the device to PC via the provided USB2.0 cable for Charging and File Transfer purposes.

  • Page 10: Getting Started

    GETTING STARTED Power ON Press and hold the key for a few seconds to turn on the device as illustrated below: Power OFF Press and hold the key for a few seconds to turn off the device as illustrated below: Volume adjustment Press the key to increase or decrease the volume...
  • Page 11 GETTING STARTED Battery low When the battery power level is very low, a message will be shown on the current interface as below. It is advised that you charge the player, or it may power off automatically during use.: Low Battery •...
  • Page 12 ) for the third time, it changes to the EQ mode (Normal, Pop, Rock, Jazz or Classic) as illustrated below. CONNECTING TO A PC Connect C230 to PC Connect the supplied USB cable to the USB port on player and to an available USB port on your computer.
  • Page 13 BUILD MUSIC LIBRARY After turning on the device, it will go through a process of building music library. It is a process of updating and reorganizing the database as illustrated below: FORMAT THE DEVIC E (Formatting is not required unless data corruption has occurred) Windows 2000 For Window ME or 2000, connect the device with PC, right click the removable drive in “My Computer”...
  • Page 14 PD Video Converter specification 1. Input format: WMV (*.wmv), AVI (*.avi), MPEG (*.mpeg, *.dat) 2. Output format: AVI (video codec: Xvid, Aud io codec: mp3) 3. O.S. support: Microsoft Windows 2000 / XP / Vista Download and install the application & required library 1.
  • Page 15 2. Select “Download PDConverter” and download the latest version of the application. 3. Execute the downloaded installer files to start the installation. 4. Follow the on-screen instruction to complete the installation. - 4.1 Click the next step to go to the next step.
  • Page 16 - 4.2 Select the installation path and click next. - 4.3 Click the install to start the installation.
  • Page 17 - 4.4 The driver is installed during the installation ( if your O.S. is Windows XP, one warning dialog will appear and please select “Continue Anyway” ) - 4.5 Click “Finish” button to complete the installation of the application.
  • Page 18 5. Select “Download Xvid” and download the latest version of the required library. 6. Execute the downloaded installer files to start the installation. 7. Follow the on-screen instruction to perform the installation. Launching of the application 1. After the installation, go to the “Start-> Programs” and find the “PDConverter” 2.
  • Page 19 Configuration of the application 1. Select the conversion parameters 2. Select your target location for the output file(s) by clicking the “...” (e.g. “C:\ temp”). Way to convert a video clip 1. Launch the application. 2. Make sure the parameters is configurated according to [Configuration of the application] section. 3.
  • Page 21 Windows XP (MTP mode): 1. Double click "My Computer" in Windows, you will find a new drive Audio Player 2. Drag your media files to "Media" folder and other files to "Data" folder (Windows Media Player 10 installed) or "Internal Storage" (Windows media player 11 installed). Note: 1.
  • Page 22 DRM file transfer By synchronization using Windows Media Player 9 (Windows 2000) under MSC mode 1.Run Windows Media Player 9 2.Connect your player to the computer 3.Select "Copy to CD or Device". 4.Drag the desired songs, photos or converted video clips in PC to the left panel. 5.Select "Removable Disk"...
  • Page 23 i. Drag your files to the sync list on the left hand side. Click "Start Sync" and the synchronization starts. ii. Select playlist from the drop down menu of "Sync List", then click "Start Sync". Files in the list will be transferred to your device. Hint: Windows Media Player should be used to alter the Music Library Information and files.
  • Page 24 CREATE PLAYLIST USING WINDOWS MEDIA PLAYER 10 (Windows XP only) 1. Run Windows Media Player 10 2. Choose "Library", then drag the desired song(s) to the "Now Playing List" on the right hand side. 3. Select all songs in the playlist and right click the mouse. Choose "Add to" and "Additional Playlist..."...
  • Page 25 4.Select "New" and enter the playlist name, then click "OK" then a new playlist will be created. Add Playlist through Windows Media Device 10 to C230 Sync option for your device with WMP10 is set to "Manual Transfer". You can sync your playlist to your device by changing "Synchronization Settings"...
  • Page 26 4.Check "Synchronize device automatically" and check the playlist(s) you want to sync. 5.After choosing your playlist(s) to sync, click "OK" and the synchronization starts. 6.When the synchronization finished, disconnect your device from computer properly. 7.Turn on your device and select "Music". 8.Your playlist(s) from WMP is added under the "Playlist"...
  • Page 27 What is DRM ? Short for digital rights management, a system for protecting the copyrights of data circulated via the Internet or other digital media by enabling secure distribution and/or disabling illegal distribution of the data. Typically, a DRM system protects intellectual property by either encrypting the data so that it can only be accessed by authorized users or marking the content with a digital watermark or similar method so that the content can not be freely distributed.

  • Page 28: Troubleshooting

    TROUBLE SHOOTING Symptom The device cannot be turned on The battery is exhausted. No sound during playback Keys do not work WMP or PC does not recognize Make sure you have Windows XP and Windows Service There is noise during playback The file cannot be played Cannot download / upload Characters and symbols on the...

  • Page 29: Technical Specification

    TECHNICAL SPECIFICATION Category Dimensions (H x W x D) Net Weight Internal Flash Memory Power Supply PC Interface Distortion Frequency Response Operating temperature Storage temperature Relative humidity Operating altitude Audio format supported Photo Format Supported Note: The above specifications are subject to change without prior notice. Specification 87.5 X 37 X 22 MM Via USB cable...
