Upflow/horizontal and downflow gas-fired, direct/non-direct vent, single stage condensing furnaces with high efficiency motor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Installer's Guide
Upflow/Horizontal and Downflow
Gas-Fired, Direct/Non-Direct Vent, Single Stage
Condensing Furnaces with High Efficiency Motor
U U p p f f l l o o w w , , C C o o n n v v e e r r t t i i b b l l e e t t o o
H H o o r r i i z z o o n n t t a a l l R R i i g g h h t t o o r r
H H o o r r i i z z o o n n t t a a l l L L e e f f t t
A951X040BU3SAA
A951X060BU4SAA
A951X080BU4SAA
A951X080CU5SAA
A951X100CU5SAA
A951X120DU5SAA
CAUTION
Failure to follow this Caution could result in property damage or personal injury. 4GXC* and
4MXC* coils installed on upflow furnaces in vertical, horizontal left, or horizontal right
orientations without a factory installed metal drain pan shield must use a MAY*FERCOLKITAA
kit. Coils installed on upflow furnaces must have drain pans that are suitable for 400° F
(205°C) or have a metal drain pan shield. Downflow furnaces do not require a metal drain pan
shield or the use of the MAY*FERCOLKITAA kit. See Installer's Guide for more information.
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and
air-conditioning equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered
equipment by an unqualified person could result in death or serious injury. When working on the equipment, observe all precautions in the
literature and on the tags, stickers, and labels that are attached to the equipment.
August 2019
D D o o w w n n f f l l o o w w O O n n l l y y
A951X040BD3SAA
A951X060BD3SAA
A951X080BD4SAA
A951X100CD5SAA
A951X120DD5SAA
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
8 8 8 8 - - A A 9 9 5 5 1 1 X X 0 0 0 0 1 1 - - 1 1 B B - - E E N N
N N o o t t e e : : Graphics in this document are for representation
only. Actual model may differ in appearance.
