Unit Drawings

Installation Drawings

Installation drawings
clearances, exhaust details, connection locations, wiring
stub-ups, lifting locations, and other information. Use the
unit specific installation drawings when designing a site
installation plan. Thoroughly read the NOTES section of
each drawing for important details.
4
REMOVE PANEL TO INTERNAL DIVIDER PANEL
ALLOW TANK VENTS SEPARATES FUEL TANK VENTILATION
TO TERMINATE OUTSIDE DUCT FROM THE ENGINE,
OF THE GENERATOR ALTERNATOR AND EXHAUST SYSTEM
ENCLOSURE (CHECK LOCAL
AND STATE CODE FOR
APPLICABILITY)
RADIATOR/EXHAUST
DISCHARGE AIR
(BOTH SIDES)
B
173 [6.8]
618 [24.3]
LIFT-OFF DOOR PROVIDES ACCESS TO:
FUEL FILL, FUEL LEVEL GAUGE,
NORMAL VENT, INNER TANK
EMERGENCY VENT, OUTER TANK
RADIATOR/EXHAUST
EMERGENCY VENT, OPTIONAL
DISCHARGE AIR
90% ALARM ASSEMBLY,
OPTIONAL 5 GALLON SPILL
BOX
A
OPEN PUNCHED LOUVERS TYPICAL
FUEL TANK
ON BOTH SIDES OF
VENTILATION DUCT
FUEL TANK VENTILATION
DUCT TO PROVIDE ADEQUATE
CROSS-FLOW OF AIR VENTILATION
DRAWING CREATED FROM PRO/ENGINEER
3D FILE. ECO MODIFICATION TO BE
APPLIED TO SOLID MODEL ONLY.
4

Wiring Diagrams

Wiring and schematic diagrams show the connection
points for control wiring, load wiring, and any service
power supply required for battery chargers, block
heaters, etc. Always use the unit specific wiring diagrams
during planning and installation. See Section 8:
Installation Drawings for more information.
Installation Guidelines for Protector Diesel Generators
show weights, dimensions,
3
SERVICE ITEM
OIL FILL CAP
OIL DIP STICK
998 [39.3] OIL FILTER
CENTER OF GRAVITY
OIL DRAIN HOSE
SEE NOTE 5
RADIATOR DRAIN HOSE
AIR INTAKE
AIR CLEANER ELEMENT
(BOTH SIDES)
MUFFLER
FAN BELT
BATTERY
REFERENCE OWNERS MANUAL FOR PERIODIC
REPLACEMENT PART LISTINGS.
TOP VIEW
758 [29.8]
DOOR TYP
REAR ENCLOSURE COVER
PANEL
SEE NOTE 4
CIRCUIT BREAKER
SEE NOTE 3
CUSTOMER ACCESS
ASSEMBLY, CONTROL PANEL
ACCESS, BATTERY CHARGER
LOCATED WITHIN
SEE NOTE 4
REAR TANK COVER
SEE NOTE 4
EXHAUST MUFFLER ENCLOSED WITHIN
GENERATOR ENCLOSURE
LEFT SIDE VIEW
3
Figure 2-1. Typical Installation Drawing
SH REV WINDCHILL VERSION
1/2 A A.1
3.4L
WEIGHT DATA WITH EMPTY BASETANK
(SEE NOTE 5)
RIGHT SIDE
GENERATOR AS SHOWN (STEEL ENCL) 997 [2197]
RIGHT SIDE
WITH WOODEN SHIPPING SKID 1042 [2297]
RIGHT SIDE
RIGHT SIDE
NOTES:
LEFT SIDE
1. MINIMUM RECOMMENDED CONCRETE PAD SIZE: 1194 (47") WIDE X 2718
RIGHT SIDE
(107") LONG. REFERENCE INSTALLATION GUIDE SUPPLIED WITH UNIT
FRONT
FOR CONCRETE PAD GUIDELINES
2. ALLOW SUFFICIENT ROOM ON ALL SIDES OF THE GENERATOR FOR MAINTENANCE
EITHER SIDE
AND SERVICING. THIS UNIT MUST BE INSTALLED IN ACCORDANCE WITH CURRENT
LEFT SIDE
APPLICABLE NFPA 37 AND NFPA 70 STANDARDS AS WELL AS ANY OTHER FEDERAL,
STATE AND LOCAL CODES.
3. CONTROL PANEL / CIRCUIT BREAKER INFORMATION:
- SEE SPECIFICATION SHEET OR OWNERS MANUAL
- ACCESSIBLE THROUGH CUSTOMER ACCESS ASSEMBLY DOOR ON REAR OF
GENERATOR
4. REMOVE THE REAR TANK AND REAR ENCLOSRE COVER PANEL TO ACCESS
THE STUB-UP AREAS AS FOLLOWS:
- HIGH VOLTAGE CONNECTION INCLUDING AC LOAD LEAD CONDUIT CONNECTION
NEUTRAL CONNECTION, BATTERY CHARGER 120 VOLT AC (0.5 AMP MAX) CONNECTION.
- LOW VOLTAGE CONNECTIONS INCLUDING TRANSFER SWITCH CONTROL WIRES
5. CENTER OF GRAVITY AND WEIGHT MAY CHANGE DUE TO UNIT OPTIONS.
6. ENGINE SERVICE CONNECTIONS
OIL DRAIN: 3/8" NPT
EXHAUST OUTLET: 2" O.D.
7. BOTTOM OF GENERATOR SET MUST BE ENCLOSED TO PREVENT PEST INTRUSION AND
RECIRCULATION OF DISCHARGE AIR AND/OR IMPROPER COOLING AIR FLOW.
8. EXHAUST SYSTEM MAXIMUM BACK PRESSURE: 35 INCHES H2O.
9. REFERENCE OWNERS MANUAL FOR LIFTING WARNINGS.
10. MOUNTING BOLTS OR STUDS TO CONCRETE PAD SHALL BE 5/8-11 GRADE 5
(USE STANDARD SAE TORQUE SPECS)
DOORS ON FRONT, RIGHT, AND LEFT SIDES
1449
[57.0]
OVERALL
HEIGHT
343
[13.5]
182
888 [35.0]
[7.2]
OVERALL WIDTH
REAR VIEW RIGHT SIDE VIEW
GENERAC POWER SYSTEMS OWNS THE COPYRIGHT OF THIS DRAWING
WHICH IS SUPPLIED IN CONFIDENCE AND MUST NOT BE USED FOR
ANY PURPOSE OTHER THAN FOR WHICH IT IS SUPPLIED WITHOUT
THE EXPRESS WRITTEN CONSENT OF GENERAC POWER SYSTEMS.
c GENERAC POWER SYSTEMS 2013
ELECTRONICALLY APPROVED
INSIDE WINDCHILL
2
Installation Planning
1
VICE ACTION LATCH,
LIFTING PROVISIONS (4 PLACES)
ONE PER DOOR, LIFT-OFF
SEE NOTES 5, 9, AND CENTER
OF GRAVITY DIMENSIONS
1625 [64.0]
2424 [95.4] OVERALL LENGTH
TITLE
INSTALL CPL PROT D3.4L EXT
ISSUE DATE:
SIZE CAGE NO DWG NO
0K6968
B
SCALE 0.050 WT-KG SEE ABOVE SHEET
1
B
A
REV
A
1 of 2
