4.APsystems Microinverter System Installation
APsystems Microinverter&Energy Communication Unit
The APsystems Installation Map is a diagram of the physical location of each microinverter in your PV installation.
Each APsystems microinverter has a removable serial number label located on the mounting plate. Pee l the label
and affix it to the respective location on the APsystems installation map.
Installation Map Template
1 2 4 5
3
B A B A
To register your APsystems microinverter, please mail this warranty registration card to:
①. The layout of the inverters' serial numbers on the warranty card is only suitable for
general arrangement.
②. Warranty card is located in Appendix last page of this manual.
③. You can use Scanning Gun or mobile phone to scan the serial numbers on the map
when set ECU (see ECU manual).
Warranty Card
6 7 9 10 11 12
8
B A
13 14 15 16 17 18 19
emasupport@altenergy-power com
APsystems DS3 Series Installation/User Manual
20 21 22
.
Figure 11
