- Page 1 Installation / User Manual OPT700/OPT700L DC Optimizer Rev 1.1 ALTENERGY POWER SYSTEM Inc. www.APsystems.com © All Rights Reserved...
-
Page 2: Table Of Contents
Required parts and tools to complete the installation..................7 Installation Procedures............................8 Step 1 - Attaching the APsystems Optimizer to the Racking or the PV Module Frame......8 Step 2 - Connecting the APsystems Optimizer to the PV Module............... 8 Step 3 - Connecting the APsystems Optimizer DC output Cables..............9... -
Page 3: Important Safety Instructions
Important Safety Instructions This manual contains important instructions to be followed during installation and maintenance of the APsystems optimizer. To reduce the risk of electrical shock and ensure the safe installation and operation of the optimizer, the following symbols appear throughout this document to indicate dangerous conditions and important safety instructions. -
Page 4: Radio Interference Statement
A) Relocate the receiving antenna and keep it well away from the equipment. B) Consult the dealer or an experienced radio / TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance may void the user’s authority to operate the equipment. OPT700/OPT700L Installation/User Manual... -
Page 5: Symbols Replace Words On The Equipment, On A Display, Or In Manuals
Important Safety Instructions Symbols replace words on the equipment, on a display, or in manuals Trademark Caution, risk of electric shock Equipment protected throughout by double insulation or reinforced insulation Refer to the operating instructions Caution, hot surface. OPT700/OPT700L Installation/User Manual... -
Page 6: Apsystems Optimizer System Introduction
It can achieve module-level Maximum Power Point Tracking (MPPT) and plays a critical part in the whole power system. The APsystems PV Power Optimizer system is comprised of four key elements: APsystems Optimizer (OPT700/OPT700L) ... - Page 7 The APsystems Optimizer increases PV energy production by 5%-25% Each APsystems PV Power Optimizer is individually connected to one or two solar modules. Each PV module has individual Maximum Power Point Tracking (MPPT) controls, which ensures that the optimum power is exported to the utility grid regardless of the performance of the other PV modules in the array.
-
Page 8: Apsystems Optimizer System Installation
APsystems Optimizer System Installation A PV system using APsystems optimizers is simple to install. Each optimizer easily mounts on the PV racking directly beneath the PV module(s) or the module frame. Low-voltage DC wires connect from the PV module directly to the optimizer, eliminating the risk of a high-voltage DC charge. -
Page 9: Installation Procedures
Attaching to the Racking. Figure 2 b) Attaching to the PV Module Frame. Figure 3 Step 2 - Connecting the APsystems Optimizer to the PV Module Figure 4 WARNING: Connect the PV module to the optimizer INPUT1 interface when the optimizer connects with one solar module. -
Page 10: Step 3 - Connecting The Apsystems Optimizer Dc Output Cables
Peel the labels off, affix one to the respective location on the APsystems installation map, then affix another label to the PV module frame so that it can be easily seen. The warranty cards can be found in the appendix of this manual or at the APsystems website, www.APsystems.com b. -
Page 11: Step 5 - Verifying Proper Optimizer Connection
For example, each APsystems optimizer connect to two PV modules and produce a PV open circuit voltage of 80V. If ten APsystems optimizers are connected in a string, and then 800V should be produced. -
Page 12: Troubleshooting
WARNING: Only qualified personnel should directly handle the APsystems optimizer. WARNING: Do not attempt to repair the APsystems Optimizer. If troubleshooting methods fail, please return the optimizer to your distributor for replacement. When Verifying Proper Power Optimizer Connection: 1. When measuring the PV open circuit voltage, one or more of the optimizers voltage value inconsistent with others. -
Page 13: Replace A Apsystems Optimizer
Replace a APsystems Optimizer Follow the procedure to replace an APsystems optimizer: A. Disconnect the APsystems optimizer from the PV Module, in the order shown below: 1. Disconnect the AC by turning off the inverter switch. 2. Disconnect the DC by turning off the inverter switch. -
Page 14: Apsystems Opt700/Opt700L Technical Data
Safety Class Compliance EN 301489-1, EN 301489-17, EN 300328,,AS/NZS 4268 Radio Spectrum Specifications subject to change without notice - please ensure you are using the most recent update found at www.APsystems.com © All Rights Reserved 2017/04/28 REV1.1 OPT700/OPT700L Installation/User Manual... - Page 15 Mail: info@altenergy-power.com APsystems America 600 Ericksen Ave NE, Suite 200 Seattle, WA 98110 Tel: 844-666-7035 Mail: info@APsystems.com APsystems Europe Rue des Monts dor ZAC de Folliouses Sud-Les Echets 01700 Miribel, France Tel: +33-481 65 60 40 Mail: emea@APsystems.com OPT700/OPT700L Installation/User Manual...
- Page 16 The APsystems Installation Map is a diagram of the physical location of each optimizer in your PV installation. Each APsystems optimizer has a removable serial number label located on the mounting plate. Peel the label and affix it to the respective location on the APsystems installation map.
