INSTRUCTION MANUAL
Cordless Lawn Mower
DLM463
DLM464
Read before use.

Advertisement

Table of Contents
loading

Related Manuals for Makita DLM464

Summary of Contents for Makita DLM464

  • Page 1 INSTRUCTION MANUAL Cordless Lawn Mower DLM463 DLM464 Read before use.

  • Page 2: Specifications

    SPECIFICATIONS Model: DLM463 DLM464 Mowing width (blade diameter) 460 mm No load speed Normal mode 3,300 min Energy-saving mode 2,500 min Part number of replacement mower blade 199367-2 Dimensions during operation L: 1,319 mm to 1,518 mm (L x W x H)
  • Page 3 While operating the mower, always wear sub- Always keep a firm hold on the handle. stantial footwear and long trousers. Do not 12. Always be sure of your footing on slopes. operate the mower when barefoot or wearing 13. Walk, never run. open sandals.
  • Page 4 29. Never operate the mower with defective 48. Do not replace the battery in the rain. guards or shields, or without safety devices, 49. Avoid dangerous envionment. Don't use the for example deflectors and/or grass basket, in tool in dump or wet locations or expose it to place.
  • Page 5 Avoid storing battery cartridge in a con- causing fires, personal injury and damage. It will tainer with other metal objects such as also void the Makita warranty for the Makita tool and nails, coins, etc. charger. Do not expose battery cartridge to water Tips for maintaining maximum or rain.

  • Page 6: Installing The Handle

    Installing the handle NOTE: The handle height can be adjusted in three levels by replacing the bolt in one of the three holes on each side of the mower body. For details, refer to NOTICE: When installing handles, position the the section for adjusting the handle height.

  • Page 7: Installing The Grass Basket

    Installing the grass basket Open the rear cover. ► 1. Lever 2. Mulching attachment For DLM464 ► 1. Rear cover Open the rear cover. Hook the grass basket on the rod of the mower body as shown in the figure.
  • Page 8 For DLM464 For DLM464 Open the rear cover, and then remove the grass CAUTION: Be sure to install the grass basket basket. included in the product package. Installing other grass baskets to the machine may cause a malfunc- tion and cause an injury.

  • Page 9: Functional Description

    Insert the lock key in the place shown in the figure FUNCTIONAL DESCRIPTION as far as it will go. Installing or removing battery cartridge CAUTION: Always switch off the tool before installing or removing of the battery cartridge. CAUTION: Hold the machine and the battery cartridge firmly when installing or removing bat- tery cartridge.

  • Page 10: Control Panel

    Indicating the remaining battery Control panel capacity The control panel has the main power switch, the mode switching button, and the indicator of remaining battery Only for battery cartridges with the indicator capacity. ► 1. Indicator lamps 2. Check button Press the check button on the battery cartridge to indi- cate the remaining battery capacity.

  • Page 11: Adjusting The Mowing Height

    If you notice anything unusual with either of these switches, stop operation immediately and have them checked by your nearest Makita Authorized Service Center. Install the battery cartridges. Insert the lock key into the interlock switch and then close the battery cover.

  • Page 12: Adjusting The Handle Height

    Grass level indicator Loosen the thumb nuts of the lower handle, and then remove the bolts, washer, and thumb nuts. For DLM464 only Grass level indicator shows the volume of mowed grass. When the grass basket is not full, the indicator floats while the blades are running.

  • Page 13: Electronic Function

    Electronic function The machine is equipped with the electronic functions for easy operation. • Constant speed control Electronic speed control for obtaining constant speed. Possible to get fine finish, because the rotating speed is kept constant even under load condition. OPERATION Mowing The center lines of the front wheels are guidelines to...

  • Page 14: Maintenance

    The cut grass may also block up inside of the mower body. repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Emptying the grass basket Centers, always using Makita replacement parts.
  • Page 15 Storing Removing or installing the mower blade Store mower indoors in a cool, dry and locked place. Don't store the mower and charger in locations where WARNING: Always remove the lock key and the temperature may reach or exceed 40 °C (104 °F). battery cartridge when removing or installing the Open the rear cover and take out the grass basket blade.

  • Page 16: Troubleshooting

    Before asking for repairs, conduct your own inspection first. If you find a problem that is not explained in the manual, do not attempt to dismantle the tool. Instead, ask Makita Authorized Service Centers, always using Makita replace- ment parts for repairs.
  • Page 20 Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885846-926 www.makita.com 20200720...
