FUNCTIONAL DESCRIPTION

V................................. Volts
A ................................. Amperes
Hz .................................. Hertz
~
.................................. Alternating Current
5
6
7
DEFINITION OF SYMBOLS
USED ON TOOL
.................................. Alert
.................................. Wear Eye Protection
.................................. Wear Ear Protection
4
1. Nail Pusher Rod Assembly
2. On/Off Switch
3. Power Cord
4. Trigger
5. Guide Light
6. Non-Marring Bumper
7. Safety Tip
