Henderson LORETTO Fitting Instructions

FITTING INSTRUCTIONS - NOTICE DE POSE - MONTAGE HANDLEIDING - MONTAGEANLEITUNG
Warranty. This product is covered by a 10 year manufacturer's warranty. Please see the P C Henderson website for terms and conditions.
WATCH THE INSTALLATION VIDEO
Visit: www.pchenderson.com/loretto-installation
Or scan the QR code using your phone
B = 19 to 45mm
23kg
OPENING WIDTH/
TRACK LENGTH
ISTRUZIONI DI MONTAGGIO - INSTUCCIONES DE MONTAJE
KIT
D4
D5
Y
D6
LORETTO
A = Y + 20mm
2
Y
Z
H
H = Z -5
10
10
W
W = B +3
1.6
16
OPENING WIDTH/
TRACK LENGTH (Y)
1200mm
1500mm
1800mm
1-3
A
3
MAX DOOR No. OF DOORS
WEIGHT
23kg
23kg
23kg
B
2
2
2
