SHUTTER SLIDE
2 and 3 Panel Telescopic System - Manual or Automated
Fitting Instructions
No. of Panels
Operation
Manual
2
Automatic
Manual
3
Automatic
HH4/AN Track Stop
120 Track
2 Door (x2)
2 Door (x2)
3 Door (x2)
3 Door (x3)
GSSUR Channel
GSSULR Channel
OR
2 Door (x2)
3 Door (x3)
GSS/SSK10 Guide
GSS/SBK10 Guide
2 Door (x2)
OR
3 Door (x3)
E/B10 Belt Clamp (x1)*
OR
E120/24V
Motor (x1)*
SYSTEM AND PANEL SPECIFICATION
Min. Panel Width
500mm
500mm
500mm
500mm
SYSTEM COMPONENTS
WP**F Fascia
(x1)
Additional Belt Clamp
2 Door (x2)
2 Door (x1)
3 Door (x3)
3 Door (x2)
GSS/SL Guide 2
2 Door (x2)
OR
Door (x2) 3
3 Door (x3
Door (x3)
Control Panel (x2)*
E120/230V Motor
(x1)*
Max. Panel Width
1200mm
35 - 47mm
1200mm
35 - 47mm
1200mm
35 - 47mm
1200mm
35 - 47mm
WP**T Wall Fixing
Profile (x1)
Datum Block
(x1)
GSS/RH Offset
Angle Plate Right
(x1)
E2/RCK Remote
(x1)
Note: Fixings not supplied by P C Henderson, please choose suitable
fixings for the relevant application environment.
* Automated only
**Full short code depends on system installed
Components vary depending on specification
Page 1
Panel Thickness
Max Panel
Range
120kg
80kg
120kg
60kg
WP***/EC End
Toothed Belt
Caps (x2)
Long Arm
Short Arm
2 Door (x1)
2 Door (x1)
3 Door (x2)
3 Door (x2)
E/PA10 Pulley
GSS/LH Offset
OR
Angle Plate Left
(x1)
GSS/MK** L Plate
2 Door (x2)
3 Door (x3)
Weight
(x1)
(x1)*

Advertisement

loading
Need help?

Need help?

Do you have a question about the SHUTTER SLIDE and is the answer not in the manual?

Questions and answers

Related Manuals for Henderson SHUTTER SLIDE

Summary of Contents for Henderson SHUTTER SLIDE

  • Page 1 Control Panel (x2)* E2/RCK Remote GSS/MK** L Plate (x1) 2 Door (x2) 3 Door (x3) Note: Fixings not supplied by P C Henderson, please choose suitable fixings for the relevant application environment. E120/24V E120/230V Motor * Automated only Motor (x1)*...

  • Page 2: Tools Required

    Posi Drive Scissors Spirit Level Allen Keys Measure Screwdriver SYSTEM OVERVIEW & TRACK INSTALLATION Shutter Slide Elevation 3 Door Telescopic 2 Door Telescopic DT = Door Thickness TSH = Track Set Height DH = Door Height S = Gap Required Between Tracks X = PCH Recommended Top Clearance (63.5mm)
  • Page 3 TWO PANEL TELESCOPIC SYSTEM OVERVIEW = Apron plate position PCH RECOMMEND OL = 70mm DW = Door Width APP = 2 X DW – 140 APP = Maximum Clear Opening Width DW = (APP + 140) / 2 OL = Overlap of doors (recommended 70mm) Shutter Open Final Position THREE PANEL TELESCOPIC SYSTEM OVERVIEW...
  • Page 4 AUTOMATED TELESCOPIC OVERVIEW 2 DOOR SYSTEM Component Overview Belt Hanger Short Arm Long Arm Motor Belt Clamp Belt Clamp (Additional Door) (Automation) Datum Point Belt Overview Pulley Wheel End Stop 3 DOOR SYSTEM Hanger Component Overview Short Arm Long Arm Motor Belt Clamp Belt Clamp...
  • Page 5 STEP BY STEP INSTRUCTIONS STEP 1: Cut track and track profile to the required length (cut an extra 16mm off track when installing an automated system). Drill holes in the track (hole size depends on fixing method) and use "V" to ensure holes are central.
  • Page 6 STEP 2: Manual: Fit apron plates 32mm (min.) from edge of door. Automated: Fit apron plates 150mm from edge of door. Manual and Automated: Ensure apron plates are equal distance from either edge of door. Once positioned correctly, screw into place. MANUAL AUTOMATED 150mm...
  • Page 7 STEP 5: Attach short arm in-line with edge of door. Follower Shutter 4.5 x 30 Wood Screws STEP 6: Insert stops, hangers and pulley wheel into the track in the order shown. Note: Pulley wheel is for automated installations only. Insert into the front track only.
  • Page 8 STEP 8: Loop belt around bearing wheels and cut belt to length. STEP 9: Hang the shutter onto the track, set the height and tighten into position. i. Set Shutter height by rotating strap bolt on flats ii. Once position set – tighten thin nut against apron plate.
  • Page 9 STEP 11: Align shutters with spirit level to position fixed floor guide Spirit Level Datum Wall STEP 12: Using appropriate fixings, fit the L plate fixing guide to the edge of the opening. Next, attach the guide using an allen key to tighten into place. Adjust door stop if required before fixing to ensure the door is vertical.
  • Page 10 STEP 13: Floor guide overview Follower Door Lead Door Adjustable Floor Guide STEP 14: Automated: Loosen belt clamp, cut to length and tighten to secure belt. Belt Tighten to clamp belt STEP 15: Automated: Push tensios wheel assembly so that the belt is taut and secure assembly in position by tighening the M6 grub screw Tighten once position set...
  • Page 11 STEP 16: Set track stops to limit travel STEP 17: Loop belt around follower shutter pulley wheel an clamp to lead shutter using the belt. Lead and follower shutter overview Bracket fixed to Door Belt clamped to bracket Page 11...
  • Page 12 STEP 18: Follower shutter 1 and follower shutter 2 overview (3 door only) Follower Shutter 2 Follower Shutter 1 Belt runs in front of belt bracket Bracket to be fixed to shutter STEP 19: With shutter in fully closed position, mark the position for the datum block. Mark position of datum block by aligning with edge of follower shutter...
  • Page 13 Secure track stop using allen key STEP 22: Clip on fascia and screw on end caps Fascia P C Henderson Ltd, Durham Road, Bowburn, Co. Durham, DH6 5NG, UK 668667 Export Sales UK Sales LVL01 t: +44 (0) 191 377 7346...
  • Page 14 Page 14...
