Henderson Rustic 80 Fitting Instructions

FITTING INSTRUCTIONS - NOTICE DE POSE - MONTAGE HANDLEIDING - MONTAGEANLEITUNG

Tools Required

Screwdriver
Pencil

Contents of Kit

*M8x85 (x5) 2M (x7) 3M
*M8x60 (x5) 2M
(x7) 3M
*Alternative track fixings provided
*M8x25 (x5) 2M
(x7) 3M

1. Mark and drill fixing holes

50mm
OPENING
WIDTH (OW)
DW = OW +40* +40*
(DW = OW +80)
*PCH Suggests 40mm overlap
of the door to the opening.
ISTRUZIONI DI MONTAGGIO - INSTUCCIONES DE MONTAJE
Spanner
(x5) 2M
(x7) 3M
(x1)
- depending on wall type
33
DOOR
WIDTH (DW)
7
3M Track
Rustic 80
Tape measure
Spirit level
(x2)
(x2)
(x1)
(x2)
C L
2M Track
470mm
470mm
470mm
50mm
Power drill
Drill bits
(x2)
(x1)
450mm
450mm
450mm
450mm
50mm
470mm
470mm
470mm
Ø10mm**
** Drill bit size subject to track
fixing/wall insert used.
ST4.2x25 (x2)
(x2)
Ø10mm**
