Acnodes PMH9190 User Manual

19 ” 1440 x 900 widescreen lcd
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PMH9190
User Manual
All rights reserved. Product description and product specifications are subject to change without notice.
For l a stest product information, please v i s it Acnodes' website at www.acnodes.com
14628 Central Ave. Chino, CA 91710
© C opyright 2015 Acnodes C orp.
19 " 1 4 4 0 x 9 0 0 Wide scree n L CD
O p e n F r a m e M e ta l Co n s t r u c t i o n
1 0 0 0 - n i t Hi g h B r i g h tn e s s L CD
Tel: 909. 597. 7588
Fax: 909. 597. 1939

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PMH9190 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Acnodes PMH9190

Summary of Contents for Acnodes PMH9190

  • Page 1 User Manual All rights reserved. Product description and product specifications are subject to change without notice. For l a stest product information, please v i s it Acnodes’ website at www.acnodes.com 14628 Central Ave. Chino, CA 91710 Tel: 909. 597. 7588 Fax: 909.
  • Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correct ness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.

  • Page 3: Table Of Contents

    Contents < Part. 1 > PMH9190 Package Content Structure Diagram & Dimension P.2 - 3 Mounting Hardware & Installation < Part. 2 > Specifications / OSD Product Specifications P.5 - 6 On-screen Display Operation ( OSD ) < Part. 3 >...
  • Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.

  • Page 5: Part. 1 > Pmh9190

    < Part 1 > < 1.1 > Package Content PMH9190 W19" High Brightness LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 Basic I/O Power DVI-D AV2.2D upgrade I/O Audio Power BNC S-Video...

  • Page 6: Structure Diagram & Dimension

    (W x D x H) Weight Weight 505.5 x 59.6 x 335.1 mm 662 x 115 x 533 mm 5 kg 10 kg PMH9190 19.9 x 2.3 x 13.2 inch 26.1 x 4.5 x 21 inch 11 lbs 22 lbs...
  • Page 7 < 1.2 > Dimension Front View Side View UNIT : mm Rear View 1mm = 0.03937 inch Bottom View...
  • Page 8 < 1.3 > Installation ( I ) Universal mount ( II ) VESA mount ( 100*100mm ) M4 screw Hardware and M4*4 pcs for VESA mounting are not provided...

  • Page 9: Product Specifications

    < Part 2 > < 2.1 > Product Specifications PMH9190 Mechanical Design Front Panel Rear Casing Dark grey, RAL 7037 VESA Mounting 100 x 100mm Other Mounting Universal mount Protection Panel Size ( diagonal ) 19-inch Widescreen TFT color LCD...
  • Page 10 Physical Product ( W x D x H ) 505.5 x 59.6 x 335.1 mm Specification 19.9 x 2.3 x 13.2 inch Packing ( W x D x H ) 662 x 115 x 533 mm 26.1 x 4.5 x 21 inch Net Weight 5 kgs / 11 lbs Gross Weight...

  • Page 11: On-Screen Display Operation ( Osd )

    < 2.2 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &...

  • Page 12: Part 3 > Options

    < Part 3 > Options < 3.1 > Option Table Options SDI *** HDMI * or DVI-D S-Video * + Composite ( BNC ) Audio Touchscreen MCS multi-display control DC Power MIL-type / lockable connector Quad display TV ( Analog ) * Auto / switch dimming About SDI ( 1 ) The AD board will be upgraded to version 3.0, and this comes standard with HDMI, DVI-D,...
  • Page 13 < 3.2 > Options : 3G / HD / SD-SDI input Acnodes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with Full HD 1080p and ultra high resolution 1920 x 1200 LCD displays, Acnodes provides a SDI input module without using additional space or power and it comes standard with a 2-year warranty.
  • Page 14 < 3.3 > Options : MCS More control is always good. Especially when it is necessary and easy. Acnodes provides MCS solution to control the OS D of ( Multi-display Control ) various LCD display up to 64 units. The RS-232C is used for the communication bet ween the PC and...
  • Page 15 < 3.4 > Options : AV2.2D Upgrade Options - DVI-D ( DVI-D TMDS single link ) - AV ( S-Video + Composite, BNC ) - Audio ( 3.5mm audio jacks for audio in & out, and 2W + 2W speakers ) Audio Power BNC S-Video DVI -D...
  • Page 16 POWER Sw itches on or off the TV MUTE Turn on or off the speaker Sw itch to AV mode Select channels. For channel numbers 10 and above, 0- 9 enter the second digit within t w o seconds. V + / - Increase or decrease the speaker volume CH + / - Increase or decrease the channel number...
  • Page 17 < 3.5 > AV3.0 Upgrade Options : - HMDI ( HDMI 1.1, CEA-861-D ) - DVI-D ( DVI-D TMDS single link ) - AV ( S-Video + Composite, BNC ) - Audio ( 3.5mm audio jacks for audio in & out, and 2W + 2W speakers ) Audio Power BNC S-Video DVI -D...
  • Page 18 < 3.6 > Options : Touchscreen & driver HW19" USB Touchscreen Specification Model TRB e-Resistive TCB e-Capacitive Technology 5-Wire Resistive Capacitive Single Single Touch Point Input Type Finger or Stylus Finger Resolution 2048 x 2048 2048 x 2048 Touch Point Accuracy Response Speed 15 ms 20 ms...
  • Page 19 < 3.6 > Options : Touchscreen & driver TRB / TCB Driver Please follow the below steps to setup the touch screen:- Step 1. Run the bundled CD disc Step 2. Double click the Setup.exe Step 3. Follow the installation instruction to finish the setup Step 4.
  • Page 20 < 3.7 > Options : DC Power Model Input rating Input voltage: 24-Volt 48-Volt Input range: 18 ~ 36V 36 ~ 75V Input current - No load 50 mA 50 mA - Full load 4880 mA 2442 mA Output rating Output voltage: 12-Volt 12-Volt...
  • Page 21 < 3.8 > Options : MIL-type or Lockable Connector Input Part no. MIL Standard MIL - DTL - 26482 MS 3470W 8- 33P MIL - type DC Power Connector ( Male ) MS 3470W 14- 15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with...
  • Page 22 < 3.9 > Options : Quad Display QD Specification Item Description Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16.7 M Imaging System NTSC Resolution 1024 x 525 1024 x 625 Refresh Rate 1.0 Vpp, 75 Ohm x 4 Camera Input Video Input 1.0 Vpp, 75 Ohm x 1...

  • Page 23: Tv ( Analog )

    < 3.10 > Options : TV ( Analog ) Audio Power BNC S-Video HDMI out - in - in Video PC For TV option : ( 1 ) The AD board comes standard with HDMI, VGA, S-Video, BNC, audio inputs and RC-2 remote controller.
  • Page 24 How to Use RC-2 Remote Controller I N P U T MUTE -/-- A U T O FREEZE MENU SELECT ASPECT SLEEP ENT ER BACK EXIT SWAP S O U R C E POSI TION AUDIO INPUT Select the source Sw itches on or off the TV Only use in TV mode.
  • Page 25 < 3.11 > Options : Auto Dimming DA-01 Light sensor on OP model DA-01 Light sensor on AP model ( 66cm from A D board to sensor end ) DA-01 light sensor will be installed on the display front panel when auto dimming is ON in OSD menu.
