Summary of Contents for Viglen VIG555M

  • Page 1 VIG555M Motherboard Manual C O M P U T E R S N E T W O R K S S O L U T I O N S...
  • Page 2 Viglen’s Environment laboratory To gain a 'CE' mark, the Viglen computer range has had to undergo many difficult tests to ensure it is Electromagnetically Compatible. These are carried out in the in-house 'Environment lab' at Viglen Headquarters.
  • Page 3 Business Machines Corporation. Pentium® and Pentium® Pro are registered trademarks of Intel® Corporation. All other trademarks are acknowledged. JAC-UP, Genie, Contender, Dossier, Vig, Viglen, and Envy are trademarks of Viglen Limited. Copyright and Patents This manual and all accompanying software and documentation are copyrighted and all rights reserved.
  • Page 4: Table Of Contents

    The Power-On Sequence Phoenix BIOS – Introduction BIOS Upgrades Using AWDFALSH to Update the BIOS Configuring the Motherboard using BIOS Setup BIOS Setup Program BIOS Menu Screen Main Menu Main Menu items Standard CMOS Features Advanced BIOS Features V1.0 VIG555M Motherboard Manual...
  • Page 5 PC Health Status Frequency/Voltage Control Main Menu Additional Options Chapter 5: Technical Information Enhanced IDE Operating Systems and Hard Drives Power Supply Connector Other Useful Connectors Other Information Reliability Temperature Chapter 6: Glossary Notes Chapter 7: Suggestions V1.0 VIG555M Motherboard Manual...
  • Page 6: Chapter 1: Motherboard Overview

    Chapter 1: Motherboard Overview Introduction This manual describes the Viglen Vig555M motherboard inside your computer. The motherboard is the most important part of your computer. It contains all of the CPU, memory and graphics circuitry that make the computer work.
  • Page 7: Feature Summary

    Feature Summary The Vig555M motherboard supports Intel® Pentium® 4 processors LGA 775 pin with up to 1MB of second-level cache integrated in a LGA 775 Socket package operating at speeds up to 3.8GHz. The Celeron processor 775 pin with 128K second-cache with 400MHz system bus is also supported up to 3.2GHz.
  • Page 8 The Pentium 4 processor comes in a LGA package that connects to the motherboard through a socket 775 connector. The package consists of: • Processor card including the processor core and the second-level cache, burst pipelined synchronous static RAM (BSRAM) and tag RAM. • Thermal plate. • Back cover. V1.0 VIG555M Motherboard Manual...
  • Page 9 • ACPI & On-Now Accelerated Graphics Port (AGP) The Vig555M features both integrated graphics and an AGP port. When using the integrated graphics then a dynamic portion of the main system memory is used as video memory. You can also use any AGP video card, with 4x/8x AGP performance.
  • Page 10 USB peripheral can be connected to each port. For more than eight USB devices, an external hub can be connected to either port. The motherboard fully supports the universal host controller interface (UHCI) and uses UHCI- compatible software drivers. V1.0 VIG555M Motherboard Manual...
  • Page 11 1.44MB and 720KB DOS-formatted diskette and is supported by Windows 95 and Windows NT operating system. The Vig555M board allows connection of an LS-120 compatible drive and a standard 3½” floppy drive. The LS-120 drive can be configured as a boot device before a floppy drive, if selected in the BIOS setup utility.
  • Page 12 By default, the I/O controller interfaces are automatically configured during boot up. The I/O controller can also be manually configured in the Setup program Serial Ports One 9-pin D-Sub serial port connector is located on the back panel and is compatible with NS16C550 UARTs. V1.0 VIG555M Motherboard Manual...
  • Page 13 This key sequence resets the computer’s software by jumping to the beginning of the BIOS code and running the Power-On Self Test (POST). Audio Subsystem The Vig555M board has multiple AC ’97 V 1.03 compliant audio features including an Analog Devices ALC 655 codec. The audio subsystem includes these features: •...
  • Page 14 This utility eliminates the need to enter the Set-up program after you install an IDE drive. Expansion Slots The system has two PCI bus add-in card connectors and One AGP universal connector. V1.0 VIG555M Motherboard Manual...
  • Page 15: System Board Components

    K: ATX 20 pin Z: USB header 1 L: ATX 4 pin AA: USB header 2 M: North Bridge BB: Floppy connector N: 775 pin CPU socket CC: PCI slots O: DIMM socket 1 and 2 DD: I/O chip V1.0 VIG555M Motherboard Manual...
  • Page 16: Overview Of System Board Components

    This provides power directly to the CPU and to the AGP port. M – North Bridge The SIS ® 611FX provides the processor interface with 800/533/400 MHz frequency, support for Intel ® Hyper-Threading Technology, system memory interface at V1.0 VIG555M Motherboard Manual...
  • Page 17 This allows the case cables to be connected, such as HDD LED, Reset switch and power switch. W – Clear CMOS jumper Moving the jumper from the default position allows the CMOS to be cleared and reset. V1.0 VIG555M Motherboard Manual...
  • Page 18 BB – Floppy Connector Allows a floppy drive to be connected CC – PCI slots Allows two PCI devices to be connected to the board. DD – I/O chip This controls the Input and the Output on the motherboard V1.0 VIG555M Motherboard Manual...
  • Page 19: Back Panel Connectors

    This 9-pin COM1 port is for a pointing device or other serial devices. D – Parallel Port This 25-pin port allows connection of a parallel device e.g. Printer, scanner etc E –Video Graphics Adapter Port This 15-pin port is for a VGA monitor or other VGA-compatible devices. V1.0 VIG555M Motherboard Manual...
  • Page 20 6-channel audio configuration. Table 3: Audio 2, 4 or 6-channel configuration Headphone/2- 4-Speaker 6-Speaker Speaker Line In Rear Speaker Rear Speaker Light Blue Line Out Front Speaker Front Speaker Lime Mic In Mic In Bass/Center Pink V1.0 VIG555M Motherboard Manual...
  • Page 21: Chapter 2: System Board Options

    Chapter 2: System Board Options ® The VIG555M motherboard is capable of accepting Pentium 4 CPU’s. RAM can be upgraded to a maximum of 2GB using DDR266, DDR333, DDR400 SDRAM DIMMs Non ECC Unbuffered memory. WARNING! Unplug the system before carrying out the procedures described in this chapter.
  • Page 22 Make sure you are earthed and free of static charge before you open the computer case. If you are unsure about upgrading your computer, return it to Viglen so a qualified engineer can perform the upgrade. STEPS TO TAKE TO PREVENT STATIC DISCHARGE: 1.
  • Page 23: Overview Of Jumper Settings

    Overview of Jumper Settings The VIG555M motherboard contains the latest technology to offer an almost ® jumperless configuration. All Pentium 4 CPUs are automatically detected and the Speed is automatically set from the information provided by the CPU. The only jumpers present on the motherboard are for clearing all the CMOS settings.
  • Page 24: System Board Jumper Settings

    (Default Clear Turn off the system and unplug the power cord. Move the jumper from pins 1-2 (default) to pins 2-3 for about 5~10 seconds. Then move the jumper back to pins 1-2. V1.0 VIG555M Motherboard Manual...
  • Page 25 Do not move the jumper with the power on. Always turn off the power and unplug the power cord from the computer before changing the jumper NOTE: There is no jumper setting for configuring the processor speed or bus frequency. V1.0 VIG555M Motherboard Manual...
  • Page 26: Motherboard Connectors

    CDROM Audio In Super BIOS Floppy Drive Connector SiS 661FX Rear chassis Front USB Header 964L Chassis Intrusion Configuration Jumper Serial ATA Header 0 & 1 Front PCI IDE Panel Connector x Figure 4: Motherboard Connectors V1.0 VIG555M Motherboard Manual...
  • Page 27: Front Panel Connectors

    You can attach either a three pin LED or a 2 pin depending on what the case is supplied with. Power On/Off When these pins are shorted it turns the computer on or off. V1.0 VIG555M Motherboard Manual...
  • Page 28: Upgrading The Cpu

    4 processor together with Level 2 cache chips are housed in a protective package. The design of the VIG555M computer makes it a simple job to replace or upgrade the processor. To do so please refer to figure 6 and follow the instructions below: 1.
  • Page 29: Installing & Removing Memory Modules

    Hold the DIMM by the edges, lift it away from the socket, and store it in an antistatic package. 5. Reinstall and reconnect any parts you removed or disconnected to reach the DIMM sockets. V1.0 VIG555M Motherboard Manual...
  • Page 30: Expansion Slots (Pci & Agp)

    IRQ Holder for PCI steering Advanced AC’97 CODEC Standard PCI Graphics Adapter (VGA) PS/2 Compatible Mouse Port Numeric Data Processor Primary IDE Channel Secondary IDE Channel * These IRQs are usually available for ISA or PCI devices V1.0 VIG555M Motherboard Manual...
  • Page 31: Replacing The Clock/Cmos Ram Battery

    The battery has an estimated life expectancy of seven years. When the battery starts to weaken, it loses voltage; when the voltage drops below a certain level, the system settings stored in CMOS RAM (for example, the date and time) may be wrong. V1.0 VIG555M Motherboard Manual...
  • Page 32 CAUTION! Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by Viglen. Discard used batteries according to manufacturer’s instructions. The battery is listed as board component ‘S’ on the diagram on Figure 1.
  • Page 33: Chapter 3: Solving Problems

    Please remember that if you cannot solve the problem by yourself then you should contact your suppliers Technical Support for further assistance. Viglen Technical Support can be reached in the following ways: Telephone: 020 8758 7000 Fax: 020 8758 7080 Email: techsupport@viglen.co.uk...
  • Page 34: Troubleshooting Procedures

    Errors that prevent the boot process from continuing (fatal errors), are communicated by a series of audible beeps. If this type of error occurs, refer to the error codes and messages listed at the end of this chapter. 6. Confirm that the operating system has loaded. V1.0 VIG555M Motherboard Manual...
  • Page 35: Problems Operating Add-In Boards

    • If the PCI/ISA legacy board uses memory space between 80000H - 9FFFFH, run Set-up and set conventional memory to 256 K. • If the PCI/ISA legacy board uses shared memory between C8000H - DFFFH, run Set-up and enable shared memory for the appropriate memory space. V1.0 VIG555M Motherboard Manual...
  • Page 36: Problems & Suggestions

    Check that the brightness and contrast controls are properly adjusted. Check that the video signal cable is properly installed. Make sure a video board is installed, enabled, and the jumpers are positioned correctly. Reboot the system. V1.0 VIG555M Motherboard Manual...
  • Page 37 System halts before This indicates a fatal system error that requires immediate service completing POST attention. Note the screen display and write down any beep code emitted. Provide this information to your dealer service department / Technical Support. V1.0 VIG555M Motherboard Manual...
  • Page 38: Chapter 4: System Bios

    RAM (also known as the CMOS RAM) and provides a special Setup program to change this information. The BIOS in your Viglen computer is guaranteed to be fully compatible with the IBM BIOS. It has been written by Phoenix Award BIOS, an industrial leader in the field of BIOS software.
  • Page 39: Bios Upgrades

    BIOS Upgrades A new version of the BIOS can be upgraded from a diskette using the AFUDOS.EXE utility that is available from the Viglen FTP site. This utility does BIOS upgrades as follows: • Updates the flash BIOS from a file on a disk.
  • Page 40 This requires the user to choose one of two options. Either F1 to continue with the default BIOS settings loaded or DEL to enter the BIOS setup. Enter the BIOS setup and select ‘load optimized default’. Then select ‘Save & Exit setup’. V1.0 VIG555M Motherboard Manual...
  • Page 41: Configuring The Motherboard Using Bios Setup

    ESD workstation. If such a station is not available, you can provide some ESD protection by wearing an anti-static wrist strap and attaching it to a metal part of the computer chassis. V1.0 VIG555M Motherboard Manual...
  • Page 42: Bios Setup Program

    NOTE: If the system becomes unstable after changing any BIOS settings, load the default settings to ensure system stability. Select the Load Default Settings item under the Exit Menu. V1.0 VIG555M Motherboard Manual...
  • Page 43: Main Menu Items

    Press left/right or Up/Down arrow keys or PageUp/PageDown keys to display the other items on the screen. To view general help press F1. This displays help information General Help: on the particular option you are in. V1.0 VIG555M Motherboard Manual...
  • Page 44 Frequency/Voltage Control: For changing the CPU frequency and displaying current frequency information Load Optimized Defaults: loads BOIS default values BIOS setting password: option that allows a password to be set to access and change BIOS settings. V1.0 VIG555M Motherboard Manual...
  • Page 45 BIOS CMOS setup utility and exit out of the BIOS CMOS setup utility. Exit Without Saving: this option will not save any changes made that have been made whilst using the BIOS CMOS setup utility and exit out of the BIOS CMOS setup utility. V1.0 VIG555M Motherboard Manual...
  • Page 46: Standard Cmos Features

    3.5 in.] Halt On: This item determines whether the system stops if an error is detected during system boot-up. Options that are given are: [All Errors] [No Errors] [All, But keyboard] [All, But Diskette] [All, But Disk/Key] V1.0 VIG555M Motherboard Manual...
  • Page 47 DMA Mode: Allows the hard drive direct access to the memory. Hard Drive S.M.A.R.T: If the hard drive used supports S.M.A.R.T ( Self-Monitoring, then this allows all the functions to be used. Analysis and Reporting Technology) Size: This indicates the capacity of the hard drive. V1.0 VIG555M Motherboard Manual...
  • Page 48: Advanced Bios Features

    Hyper-Threading Function: This allows full functionality of hyper-threading CPU’s to be used. MPS Table version: The version of the MPS table being used. Set Limit CPUID MaxVal to 3: Sets the CPUID limit to 3 V1.0 VIG555M Motherboard Manual...
  • Page 49 Boot Device: The 2 device the system tries to boot from Boot Device: The 3 device the system tries to boot from Boot from other Device: Allows another device to be booted from such as a USB device. V1.0 VIG555M Motherboard Manual...
  • Page 50: Advanced Chipset Features

    Advanced Chipset Features Figure 16: Advanced Chipset Features DRAM Clock/Timing Control: Allow control over the timing of the DRAM AGP & P2P Bridge Control: Allows control over the AGP Bridge OnChip AGP Control: Controls the AGP V1.0 VIG555M Motherboard Manual...
  • Page 51: Dram Timing Control

    Allows the used to select the CAS latency time in HCLKs of 2, 2.5 or 3. The value is set the factory depending on the DRAM installed. DO NOT change the values in this field unless you have changed the DRAM or CPU. V1.0 VIG555M Motherboard Manual...
  • Page 52: Agp & P2P Bridge Control

    AGP Aperture Size: This controls how much system RAM is allocated to the AGP for video purposes. AGP Fast Write Support: Enables and disables AGP fast write support. AGP Data Rate: This allows the user to control the AGP card data transfer rate. V1.0 VIG555M Motherboard Manual...
  • Page 53: Onchip Agp Control

    VGA. In the case above the memory being used for the VGA is 32MB; this also means that 32MB will be de-allocated from the main memory. Graphics Engine Clock: This displays the speed at which the Graphics clock is running. V1.0 VIG555M Motherboard Manual...
  • Page 54: Integrated Peripherals

    Integrated Peripherals Figure 20: Integrated Peripherals Integrated Peripherals: Integrated peripherals sub menus V1.0 VIG555M Motherboard Manual...
  • Page 55 PCI audio add-on card. SIS Serial ATA Controller: Enables support for SATA devices. SIS 10/100 EHTERNET: Enables the on-board LAN On-board LAN option ROM: Enables LAN boot ROM support V1.0 VIG555M Motherboard Manual...
  • Page 56: Onchip Ide Device

    ESC:Exit F1:General Help F5:Previous Values F7: Optimized Defualts Figure 22: OnChip IDE Device Internal PCI/IDE: Used to enable or disable the internal PCI IDE channel. IDE DMA transfer Access: Enables DMA access for the IDE device V1.0 VIG555M Motherboard Manual...
  • Page 57: Onchip Pci Device

    UART Mode Select: Sets the mode for the serial port. Onboard Parallel Port: Sets the IRQ for the Parallel port Parallel Port Mode: Sets the mode for the Parallel port. ECP Mode Use DMA: Sets the DMA used by the Parallel port. V1.0 VIG555M Motherboard Manual...
  • Page 58: Power Management Setup

    Power button function: This dictates how the power button operates. Restore on AC power lost: This dictates how the system reacts to total power loss. Wake up Event Setup: Configures the events that may wake the system. V1.0 VIG555M Motherboard Manual...
  • Page 59 Resume By PCI device (PME#): Wakes the system from power saving mode when a signal is received from a specific hardware peripheral or component. MACPME Power Up Control: This is WOL function. Resume By RTC Alarm: Allows an alarm time to be set to wake the system. V1.0 VIG555M Motherboard Manual...
  • Page 60: Pnp/Pci Configurations

    F7: Optimized Defualts Figure 26: Power Management Setup Primary Graphic’s Adaptor: Sets which type of graphics adaptor is being used. PCI Latency Timer: Sets the Latency timer for the PCI bus. IRQ Resource Arrange: Sets the IRQ’s V1.0 VIG555M Motherboard Manual...
  • Page 61: Irq Resources

    ↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F7: Optimized Defualts Figure 27: IRQ Resources IRQ Resources: Allows system IRQ to be reserved be made available for motherboard or operating system to assign as required. V1.0 VIG555M Motherboard Manual...
  • Page 62: Pc Health Status

    PC Health Status: Monitors all the various speeds, temperatures and voltages over the board. PC Health Status: These are unchangeable as they give the current statues of the CPU, environment temperatures, fan speeds and the system power voltage. V1.0 VIG555M Motherboard Manual...
  • Page 63 PC Health Status Figure 29: PC Health Status PC Health Status: displays information monitored of the CPU temperature, system temperature, system fan speeds and PSU voltages. V1.0 VIG555M Motherboard Manual...
  • Page 64: Frequency/Voltage Control

    Adjust CPU Ratio: Allows the CPU clock ratio to be changed if it isn’t locked. Memory Voltage: Sets the voltage used by the memory AGP Voltage: Sets the voltage used by the AGP slot Spread Spectrum: If enabled, could reduce the EMI (Electro-Magnetic Interference) generated by the system. V1.0 VIG555M Motherboard Manual...
  • Page 65: Main Menu Additional Options

    Save & Exit Setup: Allows the settings that have been changed to be saved and exits the BIOS setup menu. This also reboots the machine. Exit Without Saving: Exits the BIOS setup menu without saving any setting that have been changed. This also reboots the machine. V1.0 VIG555M Motherboard Manual...
  • Page 66: Chapter 5: Technical Information

    Block Addressing), and the OS supports LBA, or uses the BIOS to access the disk. Extended CHS mode also overcomes the 528MB maximum size limitation imposed by Standard CHS mode. It can be used with drives which are larger than 528MB that do not support LBA. V1.0 VIG555M Motherboard Manual...
  • Page 67 If this driver is not installed and the drive fitted to the system supports Type F DMA on the ISA interface or Mode 3 on the PCI interface then higher performance will be achieved by NOT using '32-bit Disk Access'. V1.0 VIG555M Motherboard Manual...
  • Page 68: Power Supply Connector

    Pin Signal Name Name Sleep/Power +5 V HDD LED +5V HDD LED Green Sleep/Power HDD LED OV HDD LED Yellow Power Switch SWITCH ON RESET RESET Power Switch Ground RESET Ground No connection 10 None connection V1.0 VIG555M Motherboard Manual...
  • Page 69 Audio Right Out Table 17: Audio Line In Connector Signal Name Sleeve Ground Audio Left In Ring Audio Right In Table 18: Audio Mic In Connector Signal Name Sleeve Ground Mono In Ring Electret Bias Voltage V1.0 VIG555M Motherboard Manual...
  • Page 70 AD14 A15 RST# Ground AD13 Ground A16 +5 V (I/O) AD11 AD12 A17 GNT# Ground Ground AD10 A18 Ground REQ# AD09 Ground A19 PME# +5 V (I/O) A20 AD30 AD31 A21 +3.3 V AD29 C/BE0# AD08 V1.0 VIG555M Motherboard Manual...
  • Page 71 +5 V (I/O) A29 AD20 AD21 REQ64C# ACK64C# A30 Ground AD19 +5 V +5 V A31 AD18 +3.3 V +5 V +5 V These signals (in parentheses) are optional in the PCI specification and are not currently implemented. V1.0 VIG555M Motherboard Manual...
  • Page 72 Table 21: Front Panel USB Assignment Assignment Data0 - Data1 - Data0 + Data1 + Ground Ground Table 22: COM2 Assignment Assignment Ground Table 23: Internal Speaker Assignment Signal Ground V1.0 VIG555M Motherboard Manual...
  • Page 73: Other Information

    • Estimating repair rates and spare parts requirements. MTBF data is calculated from predicted data @ 55 °C. The MTBF prediction for the motherboard is 286,877 hours. Temperature Table 24: Temperature Temperature Specification Non-operating -40°C to +70°C Operating 0°C to +55°C V1.0 VIG555M Motherboard Manual...
  • Page 74: Chapter 6: Glossary

    Much of the circuitry previously required on hard disk controller cards is now integrated on the hard disk itself. Interface The electronics providing a connection between two pieces of equipment. For example, a printer interface connects a computer to a printer. V1.0 VIG555M Motherboard Manual...
  • Page 75 BIOS is responsible for this copying. Super VGA Additional screen modes and capabilities provided over and above the standard VGA defined by IBM. Video Graphics Array - the graphics standard defined by IBM and provided on IBM's PS/2 machines. V1.0 VIG555M Motherboard Manual...
  • Page 76: Notes

    Notes V1.0 VIG555M Motherboard Manual...
  • Page 77: Chapter 7: Suggestions

    Viglen is interested in continuing to improve the quality and information provided in their manuals. Viglen has listed some questions that you may like to answer and return to Viglen. This will help Viglen help to keep and improve the standard of their manuals.
  • Page 78 5. How do you rate the Viglen Technical support and Service Departments? Are there any technological improvements that could be made to the system? 7. Other points you would like to mention? Please return this slip to: Product Development Dept.
