SNM15
DIP-SWITCHES SETTING
A table summarizing the functions played by each single dip-
switch is given below:
DS2
Remember that the nominal transmission level with all the dip-
switches switched OFF is equal to 0 dBm.
Digicom SpA
1
2
OFF
OFF
ON
OFF
OFF
ON
ON
ON
OFF
OFF
ON
OFF
OFF
ON
ON
ON
OFF
OFF
ON
OFF
OFF
ON
ON
ON
OFF
OFF
ON
OFF
OFF
ON
ON
ON
3
4
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
OFF
ON
OFF
ON
OFF
ON
OFF
ON
ON
ON
ON
ON
ON
ON
ON
ON
Dip-Switches setting
Level TX
- 1 dBm
- 2 dBm
- 3 dBm
- 4 dBm
- 5 dBm
- 6 dBm
- 7 dBm
- 8 dBm
- 9 dBm
- 10 dBm
- 11 dBm
- 12 dBm
- 13 dBm
- 14 dBm
- 15 dBm
- 16 dBm
A.1
