SNM15
INTRODUCTION
OVERALL FEATURES
The SNM 15 modem is externally designed with a metal frame.
The cards are pulled out by pressing the lever located beneath the
front panel.
On the front panel there are indicating lights for the main interface
circuits, the operational condition of the modem and the operation
and test enabling switches.
On the rear panel there are the power supply cord, the protection
fuses and the mains switch. There are also the line connector and
the two ISO 2110 type female connectors to terminate the
DTE(s).
The modem is supplied together with the present manual with a
cable for the connection to the telephone plug.
Mechanical Dimensions
Width
Height
Depth
Weight
Digicom SpA
: 190 mm.
: 44 mm.
: 266 mm.
: 2 Kg.
Introduction
1.1
