PHOTOELECTRIC SENSING TECHNOLOGY
10 YEAR PERMANENT POWER SEALED BATTERY
THANK YOU for purchasing this smoke and fire alarm. This tamper-
proof alarm does not require battery changes. It has a permanent power
sealed battery which will last for approximately 10 years. This manual
includes important information regarding where to install the alarm, how
to operate, maintenance, testing and product features. It also includes
tips and information which could help protect you and your family.
Smoke Alarm Limitations and Functions ................................. 2
Recommended Location of Alarms.......................................... 3
Avoid These Locations ............................................................ 4
Early Warning .......................................................................... 4
How to Install ........................................................................... 4
Locking/Tamper Feature .......................................................... 4
Operation, Testing & Maintenance .......................................... 5
QUICK FIND
Silence Feature ....................................................................... 6
Cautions/Warnings .................................................................. 6
Battery and Alarm Deactivation ............................................... 6
Develop and Practice a Plan of Escape .................................. 7
Quick Reference Guide / Operational Summary ..................... 8
Warranty ..................................................................Back Cover
MODEL MP316S
SMOKE & FIRE ALARM WITH
READ ALL INSTRUCTIONS
Table of Contents:
Alarm Originating Feature & Reset................... 5
®
READ ALL INSTRUCTIONS
Conforms to
UL Std. 217
Single Station Smoke Alarm
Page #
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Universal Security Instruments MP316S
Summary of Contents for Universal Security Instruments MP316S
-
Page 1: Table Of Contents
Conforms to UL Std. 217 MODEL MP316S Single Station Smoke Alarm PHOTOELECTRIC SENSING TECHNOLOGY SMOKE & FIRE ALARM WITH 10 YEAR PERMANENT POWER SEALED BATTERY READ ALL INSTRUCTIONS THANK YOU for purchasing this smoke and fire alarm. This tamper- proof alarm does not require battery changes. It has a permanent power sealed battery which will last for approximately 10 years. -
Page 2: Smoke Alarm Limitations And Functions
SMOKE ALARM LIMITATIONS AND FUNCTIONS There are three basic smoke alarm types: Universal Smoke Sensing Technology , Ionization and ® Photoelectric. Universal Smoke Sensing Technology® is an ionization alarm containing patented Smart Alarm Technology. Alarms containing Universal Smoke Sensing Technology are effective at detecting fast flaming fires and slow smoldering fires. -
Page 3: Recommended Location Of Alarms
RECOMMENDED LOCATION OF ALARMS • Locate the first smoke alarm in the immediate area of the bedrooms. Try to protect the escape route as the bedrooms are usually farthest from an exit. If more than one sleeping area exists, locate additional smoke alarms in each sleeping area. If a hall is more than 40 feet (12 meters) long, install a smoke alarm at each end. -
Page 4: Avoid These Locations
AVOID THESE LOCATIONS • the garage – products of combustion are produced when you start your vehicle. • near appliances or areas where normal combustion regularly occurs (kitchens, near furnaces, gas hot water heaters). Use smoke alarms with U.S.S.T. or photoelectric sensors, or smoke alarms with Silence Feature for these areas. -
Page 5: Operation, Testing & Maintenance
Detach the breakaway alarm locking pin from the mounting bracket. FIGURE 1 Insert the pin into the hole in the side of the alarm after the alarm has been installed on the mounting plate. Refer to the diagram below for correct placement. INSERT ALARM LOCKING PIN HERE (optional) - Page 6 IMPORTANT CONSIDERATIONS YOUR ALARM HAS BEEN DESIGNED WITH A PRODUCT END-OF-SERVICE LIFE WARNING WHICH WILL SOUND AFTER APPROXIMATELY 10 YEARS OF OPERATION FROM INITIAL POWER UP. NOTE: MANUFACTURER RECOMMENDS REPLACEMENT OF THIS ALARM 10 YEARS AFTER DATE OF INSTALLATION. NOTE: NUMEROUS ALARMS OR PROLONGED ALARMING IS NOT TYPICAL AND WILL CONSUME THE BATTERY CAPACITY, SHORTENING THE LIFE OF THIS PRODUCT.
-
Page 7: Battery And Alarm Deactivation
BATTERY AND ALARM DEACTIVATION This alarm uses a sealed battery. The battery should last for approximately 10 years under normal operating conditions. The smoke alarm has a low battery indicator which is 2 chirps approx. every 60 seconds. The red LED blinks on once approx. every 2 minutes. Due to the loud 85 decibel alarm, stand at arm's length away from the alarm or use ear protection when testing. -
Page 8: Develop And Practice A Plan Of Escape
DEVELOP AND PRACTICE A PLAN OF ESCAPE BASICS OF ESCAPE PLAN o Make a floor plan indicating all doors and windows and at least two escape routes from each room. Second story windows may need a rope or chain ladder. o Have a family meeting and discuss your escape plan, showing everyone what to do in case of fire. -
Page 9: Quick Reference Guide / Operational Summary
QUICK REFERENCE GUIDE / OPERATIONAL SUMMARY ALARM AUDIBLE & VISUAL SIGNALS CONDITION RECOMMENDATION HORN RED LED New - Out Silent To activate the alarm, remove the pull tab. The alarm will sound one long beep to confirm it is powered up. Press the Test/Silence of Package button. -
Page 10: Warranty
MODEL MP316S TEN-YEAR LIMITED WARRANTY USI Electric, Inc. /Universal Security Instruments, Inc. (“USI”) warrants this product to be free from defects in material and workmanship for a period of 10 (ten) years from the date of purchase. This warranty shall not apply to any batteries used in the product or to any damage which may be caused by such batteries.
