Panasonic U-71PZH2R5 Operating Instructions Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Air Conditioner
  5. U-71PZH2R5
  6. Operating instructions manual

Panasonic U-71PZH2R5 Operating Instructions Manual

Hide thumbs Also See for U-71PZH2R5:

Advertisement

Table of Contents

Type 71
Type 100, 125, 140
Model No.
OUTDOOR UNIT
Single Split (Single-phase)
Type PZH2
U-71PZH2R5
U-100PZH2R5
U-125PZH2R5
U-140PZH2R5
Single Split (3-phase)
Type PZH2
U-100PZH2R8
U-125PZH2R8
U-140PZH2R8
Connectable indoor unit lineup
●
This booklet is the operating instructions for outdoor unit. Regarding the indoor unit, see the
operating instructions supplied with the indoor unit.
INDOOR UNIT
4-Way Cassette
Wall-Mounted
Ceiling
Low Silhouette Ducted
Ducted
Before operating the unit, read these operating instructions thoroughly and keep them for future reference.
Panasonic Corporation
1006 Kadoma, Kadoma City, Osaka, Japan
Operating Instructions
Air Conditioner
ACXF55-22950

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U-71PZH2R5 and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic U-71PZH2R5

Summary of Contents for Panasonic U-71PZH2R5

  • Page 1 Operating Instructions Air Conditioner Type 71 Type 100, 125, 140 Model No. OUTDOOR UNIT Single Split (Single-phase) Type PZH2 U-71PZH2R5 U-100PZH2R5 U-125PZH2R5 U-140PZH2R5 Single Split (3-phase) Type PZH2 U-100PZH2R8 U-125PZH2R8 U-140PZH2R8 Connectable indoor unit lineup ● This booklet is the operating instructions for outdoor unit. Regarding the indoor unit, see the operating instructions supplied with the indoor unit.
