Middle Static Pressure Duct
<At horizontal installation>
<At vertical installation>
Model No.
INDOOR UNIT
Middle Static Pressure Duct
(Type F3)
S-3650PF3E
S-6071PF3E
S-1014PF3E
OUTDOOR UNIT
Single Split
See the page 11.
(Type F3)
ENGLISH
Before operating the unit, read these operating instructions thoroughly and
keep them for future reference.
Panasonic Corporation
1006 Kadoma, Kadoma City, Osaka, Japan
Operating Instructions
Air Conditioner
WEB-ACXF55-27531-EN
Advertisement
Table of Contents
Related Manuals for Panasonic F3
Summary of Contents for Panasonic F3
- Page 1 Operating Instructions Air Conditioner Middle Static Pressure Duct (Type F3) <At horizontal installation> ENGLISH Before operating the unit, read these operating instructions thoroughly and keep them for future reference. <At vertical installation> Model No. INDOOR UNIT Middle Static Pressure Duct...
-
Page 2: Table Of Contents
Safety Precautions Thank you for purchasing this Panasonic product. This product is a commercial air conditioner indoor unit. Installation Instructions attached. Contents The following symbols used in this manual, alert you to potentially dangerous conditions to users, service personnel or... - Page 3 WARNING If the refrigerant comes in contact Do not use modified with a flame, it produces a toxic cord, joint cord, gas. extension cord or unspecified cord to prevent For safety, be sure to turn the overheating and fire. air conditioner off and also to disconnect the power before cleaning or servicing.
- Page 4 WARNING CAUTION This appliance is intended to be used by The appliance shall be stored expert or trained users in shops, in light in a room without continuously industry and on farms, or for commercial operating open flames (for use by lay persons. example: an operating gas This appliance is not intended for use appliance) and ignition sources...
-
Page 5: Precautions For Use
Precautions for Use Installation Information for Users on Collection and Disposal of Old Equipment and Used Batteries This air conditioner must be installed properly by qualified installation technicians in accordance with the Installation hese symbols on the products, packaging, Instructions provided with the unit. and/or accompanying documents mean that Before installation, check that the voltage of the electric used electrical and electronic products and... -
Page 6: Names Of Parts
Names of Parts INDOOR UNIT Type F3 (Middle Static Pressure Duct) At standard installation (Horizontal installation in the ceiling, rear side air intake) Air outlet duct * Suspension bolt * Label (attached to the lid of electrical component box) This air conditioner incorporates a biocidal product. -
Page 7: Maintenance
Maintenance WARNING CAUTION For safety, be sure to turn the air conditioner off and Never use solvents or harsh chemicals. Also, do not disconnect the power before cleaning. (Otherwise, wipe plastic parts using very hot water. (This may cause electric shock or injury may result because the fan is deformation or change in colour.) rotating at high speed.) Some metal edges and fins are sharp. -
Page 8: Nanoe™ X Function
nanoe™ X Function Display during operation of nanoe™ X Example: Initial screen of remote controller room A 20:30 (THU) SET TEMP. MODE FAN SPEED COOL °C FLAP : Under operation of nanoe™ X nanoe™ X For a freshness and cleaner environment nanoe™... -
Page 9: Troubleshooting
Troubleshooting Check before consulting or requesting services. Symptom Cause / Action Sound like streaming water is heard • Sound of refrigerant liquid flowing inside unit during operation or after operation. • Sound of drainage water through drain pipe Noise Cracking noise is heard during operation •... -
Page 10: Before Requesting Services
Troubleshooting Before Requesting Services Symptom Cause Action The air Power failure or after power failure Press the power ON/OFF button on the remote controller. conditioner does • If the breaker is turned off, turn the power on. not operate The operation (power) button is turned off. •... - Page 11 Connectable outdoor unit lineup Europe „ Refrigerant type : R32 Outdoor unit type 1-phase U-36PZH2E5 – U-50PZH2E5 U-60PZH2E5 PZH2 3-phase – – – – 1-phase – – – U-60PZ2E5 3-phase – – – – Outdoor unit type 1-phase U-71PZH2E5 U-100PZH2E5 U-125PZH2E5 U-140PZH2E5 PZH2...
-
Page 12: Specifications
Specifications Indoor unit Middle Static Pressure Duct (Type F3) Model Name S-3650PF3E S-6071PF3E S-1014PF3E Power source (Europe) 220 - 230 - 240 V～ 50 Hz Power source (Oceania) 230 - 240 V～ 50 Hz 12.1 13.4 Cooling capacity 11,600 13,600... -
Page 13: Outdoor Unit
Outdoor unit Single Split Outdoor Unit (R32) Model Name U-36PZH2E5 U-50PZH2E5 U-60PZH2E5 Europe Power source 220 - 230 - 240 V～ 50 Hz Cooling capacity 12,300 17,100 20,500 BTU/h Heating capacity 13,600 19,100 23,900 BTU/h Sound pressure level 43 / 44 45 / 48 46 / 49 dB(A) - Page 14 Specifications Outdoor unit Single Split Outdoor Unit (R32) Model Name U-36PZ3E5 U-50PZ3E5 U-60PZ3E5 U-71PZ3E5 Europe Power source 220 - 230 - 240 V～ 50 Hz Cooling capacity 12,300 17,100 20,500 24,200 BTU/h Heating capacity 12,300 17,100 20,500 24,200 BTU/h Sound pressure level 46 / 47 46 / 46 47 / 48...
- Page 15 Model Name U-71PZH2R5 U-100PZH2R5 U-125PZH2R5 U-140PZH2R5 Oceania Power source 230 - 240 V～ 50 Hz 10.0 12.5 14.0 Cooling capacity 24,200 34,100 42,700 47,800 BTU/h 11.2 14.0 16.0 Heating capacity 27,300 38,200 47,800 54,600 BTU/h Sound pressure level 48 / 50 52 / 52 53 / 53 54 / 54...
- Page 16 Specifications Outdoor unit Single Split Outdoor Unit (R32) Model Name U-60PZ2R5 U-71PZ2R5 U-100PZ2R5 U-125PZ2R5 U-140PZ2R5 Oceania Power source 230 - 240 V～ 50 Hz 10.0 12.5 14.0 Cooling capacity 20,500 24,200 34,100 42,700 47,800 BTU/h 10.0 12.5 14.0 Heating capacity 20,500 24,200 34,100...
- Page 17 Panasonic Corporation Authorised representative in EU http://www.panasonic.com Panasonic Testing Centre Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg, Germany © Panasonic Corporation 2019 WEB-ACXF55-27531-EN DC1119-11219...
