- Page 1 EN75466664.02 03- 2019 I n s t r u c t i o n m a n u a l Manuel d'instructions B e n u t z e r h a n d b u c h Manual de instrucciones I n s t r u c t i e h a n d b o e k...
-
Page 2: Table Of Contents
CONTENTS PAGE 1. RECEIPT 2. HANDLING 3. DESCRIPTION OF THE UNIT & TECHNICAL CHARACTERISTICS 4. INSTALLATION & CONNECTIONS 5. SYSTEM START-UP 6. MAINTENANCE/SERVICE INTERVALS 7. PROBLEMS/CAUSES/SOLUTIONS 8. TESTS AND GUARANTEES Original text: French version EN - 2... -
Page 3: Receipt
For your safety, we recommend the use of PPE (Personal Protective Equipment) 1. RECEIPT The installation and maintenance operations must be performed by qualified and experienced personnel. This appliance is not designed to be used by persons (including children) with limited physical, sensory or mental capabilities, or by persons with insufficient experience or knowledge, unless they are being supervised by a person responsible for their safety or have received instructions on the use of the appliance from such a person. -
Page 4: Description Of The Unit & Technical Characteristics
3. DESCRIPTION OF THE UNIT & TECHNICAL CHARACTERISTICS GENERAL INFORMATION During normal use, this unit is intended to operate under the following site conditions: - Maximum altitude: 1000 m (please consult us for higher altitudes) - Minimum and maximum temperatures: -10 °C/+40 °C - Overvoltage category: III - Pollution degree: 3 DESCRIPTION OF THE UNIT... - Page 5 LOCATION OF COMPONENTS Fan motor assembly General switch (on outer casing) Main earth terminal (on inner casing, see p. 12) Electrics box Filters Rotary heat exchanger Energy meter enclosure (if present) Indoor coil (hydraulic, electric or DX) VRF electrics box option TECHNICAL CHARACTERISTICS Air flow rates Minimum flow rate...
- Page 6 Filters M5 HEE filter F7 HEE filter F9 HEE filter Thickness: 48 mm Thickness: 48 mm Thickness: 48 mm Fire rating: M1 Fire rating: M1 Fire rating: M1 Single filtration Sizes 1000 2000 3000 5000 7500 Filter Dimensions x Number of cells/ (704x327x48) x 1 (452x435x48) x 2 (552x535x48) x 2...
- Page 7 M5 + F7 1000 2000 3000 5000 7500 1000 2000 3000 4000 5000 6000 7000 8000 9000 Qv (m³/h) M5 + F9 1000 2000 3000 5000 7500 1000 2000 3000 4000 5000 6000 7000 8000 9000 Qv (m³/h) Fan motor assembly EC motor This fan motor assembly is a direct coupling type plug fan.
- Page 8 Options and accessories Support feet and accessories To obtain a greater clearance height, fit the adjustable feet (30 to 100 mm) underneath the standard feet. Cylinder Reinforcement plate sensor The CO sensor must be positioned on the return air duct, so that it can measure the CO level emitted from the part(s) treated.
-
Page 9: Installation & Connections
Changeover thermostat for mixed coil: The customer is responsible for installation on the hydraulic system. The changeover thermostat installed on the pipe must be integrated into the insulation of the hydraulic pipe. Technical characteristics Min. WINTER temp.: 28 °C Min. SUMMER temp.: 18 °C Breaking capacity: 5(3) A. - Page 10 Fitting procedure: Affix the foam gasket along the length of the unit (50 x 20 foam gasket). Fix the roof panel(s) along the entire length of the unit. 50x20 foam gasket bonded for roof curvature Assemble the roof on the unit as per the following diagram Ø...
- Page 11 Ø 4.8 sealed rivet Detail A Screen Flat Ø 4.8 sheet metal screw Sizes N x E M x F Weight (kg) Openings 598.5 2x190 2x313 1000 Circular 698,5 2x240 2x363 2000 1188,5 1150 2x265 3x340 3000 1488,5 1149 2x310 6x220 Rectangular 5000...
- Page 12 DIMENSION OF THE HYDRAULIC CIRCUITS (Indoor hydraulic coil) VALVE CONNECTION Heating/cooling assembly 2-WAY VALVE O-ring THREE-WAY VALVE O-ring The diameter of the condensate tube on all the pans is 16 mm Sizes 1 row coil 1000 2000 3000 5000 7500 G 1/2"...
- Page 13 DIMENSION OF THE REFRIGERANT CIRCUITS (Indoor DX coil) The diameter of the condensate tube on all the pans is 16 mm Sizes 2 row coil 1000 2000 3000 5000 7500 12 mm 12 mm 16 mm 16 mm 2x16 mm Liquid inlet Connection Ø...
- Page 14 IDENTIFICATION OF TERMINAL STRIP OPTIONS X2:2 FIRE FAULT DEFAUT INCENDIE FIRE DEFAULT X2:1 FAULT SUMMARY SYNTHESE DEFAUT DEFAULT SYNTHESIS :GND AIR QUALITY/DUCT PRESSURE PRESSION GAINE / QUALITE AIR B1:OUT DUCT PRESSURE / AIR QUALITY B1:IN X2:11 ECO / COMFORT ECO / CONFORT ECO / COMFORT X2:10 X2:13...
- Page 15 in duct: CO112-ANA Duct pressure: CP51 I GND V 3 fils 3 wires techn. 3 fils techn. 3 wires Alimentation 24 Vdc 24 Vdc supply Afficheur régulateur ou Controller display or automate type actif active controller Sortie 0-10 V 0-10 V output ■...
-
Page 16: System Start-Up
• For units with DX coil, the refrigerating machine must be operational (system start-up of the refrigerating machine not provided by CIAT). • Check the tightness of all connections, • Make sure that the inside of the unit is clean, and that there are no foreign bodies inside it, •... -
Page 17: Maintenance/Service Intervals
6. MAINTENANCE/SERVICE INTERVALS Switch off the electrical supply to the air handling unit before carrying out any work Details of hinges/handles: Allen key locks, size 4 When they are unlocked, the handles are in "hinge" mode. It is possible to unlock a single row of handles to open like a conventional door. - Page 18 Exhaust FMA removal method Open the door Remove the upper and lower fixings from the electrics box Move the electrics box; a sufficient length of cable is Disconnect the various quick connectors provided Provide sufficient clearance Remove the 4 x M8 screws EN - 18...
- Page 19 Disconnect the motor's electrical connections Take out the FMA To refit, perform the operations in reverse order. Check that the box and the connectors are secure before commissioning. HEAT RECOVERY UNIT Rotary heat exchangers Check the rotation speed once a year. When stationary, the rotary heat exchangers accumulate dust and moisture at their lowest point.
-
Page 20: Problems/Causes/Solutions
It is effective for a period of 15 months from the unit invoice date in all other cases. CIAT's guarantee on motors is limited to the terms of guarantee extended by its supplier. Under no circumstances must the fitter carry out work on the motor. This will invalidate any future claims on the warranty. - Page 21 EN - 21...
- Page 22 EN - 22...
- Page 23 EN - 23...
- Page 24 Thermiques Non-contractual document. Corporation with a capital of €26,728,480 As part of our continuous drive to improve our products, CIAT reserves the right Bourg-en-Bresse Register of Trade and Companies to make any technical modifications without prior notice. no. B 545.620.114...
