PARTS LIST
SyM Description
A COVER / DECK
B COVER SUPPORT
C1 CENTER SPACER (THICK STEEL)
C2 CENTER SPACER (THIN ALUM.)
D SPRING CLAMP
E1 END SPRING SPACER (THICK STEEL)
END SPRING SPACER (THIN
E2
ALUMINUM)
LEAF SPRING 9-PLY
F
LEAF SPRING 11-PLY
G CENTER THICK STEEL SPACER
H ARMATURE MOUNTING PLATE
COIL CLAMP
I
HHCS 5/16-18 X 1/2
J COIL WASHER
K ARMATURE
CORE
L
HEX HD CAP SCRW #10-32 X 1/2
GROUND STRAP
ROUND HD MACH SCREW 10-32
X 3/8
M
NUT #10-32
#10 LOCKWASHER
POWER CORD (USA)
POWER CORD (UNITED KINGDOM)
N
POWER CORD (EUROPEAN)
POWER CORD (AUSTRALIAN)
AC POWER ENTRY MODULE IEC-
320 C-14
M3 X 8MM SCREW
P
M3 NUT
EXT TOOTH LOCKWASHER
Q CONTROL ASSEMBLY
COIL ASSY (115V/60CY)
R
COIL ASSY (220V/50CY)
T CAST IRON BASE
U ALUMINUM HOUSING
V FRONT DECAL
W SPACER SPLIT TYPE
ISOLATOR FOOT
X RD SL MACH SCREW 1/4-20 X 3/4
LOCKWASHER 1/4 INT TOOTH
QTY Part No.
(SEE NEXT PAGE)
(SEE NEXT PAGE)
(NEXT PG) 091818-002
(NEXT PG) 91819
2 91816
(NEXT PG) 097983-002
(NEXT PG) 91817
(NEXT PG) 091815-C01
(NEXT PG) 091815-A01
(NEXT PG) 091818-002
1 91813
1 91810
4 H0306401
2 81849
1 91812
1 91811
1 H0419600
2 164473-A
2 H0203102
1 H0101003
1 H0112305
0063X019
0063X022
1 ONLY
0063X023
0063X024
1 0202X224
2 6515-083-001
2 6515-083-002
2 H0112404
1 6515-085-A
091805-A
1 ONLY
091805-B
1 090992-A
1 6515-082-001
1 6515-084-001
4 0335X001
4 0207X024
4 H0205101
4 H0112705
4
