  • Page 1 Service Instructions Syntron Jogger ® Model: J-1-D...

  • Page 2: Installation

    Trouble Shooting Parts List Syntron Material Handling, LLC. reserves the right to make changes at any time, without notice and without any liability or other obligation on its part, in materials, equipment, specifications and models, and also to discontinue the manufacture and sale of models and the parts and components thereof. For further detailed information, contact Syntron Material Handling, LLC.

  • Page 3: Operation

    The vibratory amplitude of the unit is changed by a rheostat located on the control. Various deck configurations are available. See Syntron Material Handling, LLC. Syntron product literature for further details, capacities, etc. For maximum efficiency, Syntron Material Handling, LLC. recommends a maximum load of 10 pounds for the J-1-D Jogger.

  • Page 4: Troubleshooting

    *Replace vibrate Defective leaf springs *Replace Unit In contact with rigid object or adjacent surface Isolate unit Excessive noise Armature and magnet Adjust air gap assemblies making contact *Replace only with parts supplied, or recommended, by Syntron Material Handling, LLC.
  • Page 5 PARTS LIST Description Part No. COVER / DECK (SEE NEXT PAGE) COVER SUPPORT (SEE NEXT PAGE) CENTER SPACER (THICK STEEL) (NEXT PG) 091818-002 CENTER SPACER (THIN ALUM.) (NEXT PG) 91819 SPRING CLAMP 91816 END SPRING SPACER (THICK STEEL) (NEXT PG) 097983-002 END SPRING SPACER (THIN (NEXT PG)
  • Page 6 PARTS LIST (CONTINUED) STYLE Description Part Number PLASTIC DECK 104408 FL HD CAP SCREW 1/4-20 X 5/8 H0457902 COVER SUPPORT (ALUMINUM) 114795 SCREW HX HD 5/16-18 X 1-1/2 H0354624 SCREW HX HD 5/16-18 X 1-1/8 H354524 7X10 PLASTIC DECK (SHOWN CENTER SPACER (THICK STEEL) 091818-002 ABOVE)
  • Page 7 091815-A01 Important Syntron Material Handling reserves the right to alter at any time, without notice and without liability or other obligations on its part, materials, equipment specifications, and models. Syntron Material Handling also reserves the right to discontinue the manufacture of models, parts, and components thereof.
