Click "WIFI" from Settings menu (see
Figure 2-1) to enter the WIFI menu
(see Figure 2-3). When the WIF
button is displayed in blue, it means
WIFI is turned on; when the WIFI
button is grayed out, it means WIFI
is turned off. Once WIFI is turned
on and connected successfully, the
WIFI icon on the upper right corner
of the menu is highlighted.
However, if WIFI is turned on but
2-3
fails to connect, the WIFI icon is
grayed out. Click " " to return to
the previous screen and click " "
to return to the main menu.
The system will search nearby
hotspot list automatically. Click the
hotspot name to enter the password
to connect successfully. The system
will remember the password and
connect to the last connected
hotspot automatically.
2-4
The server is used for wireless data
transmission with the specific Data
Management System. Click "Server"
to enter the server IP address and
port number, and click " " to
save. Please set the instrument's
IP address and port number to be
consistent with DMS.
2-5
