Bob's Discount Furniture Bennett Assembly Instructions

Stage 1-Fitting the Unit
NOTE: It would be useful to ask
someone to he l p you at this
stage.
1. Carefully align connecting hooks &
holes into position and lock them to
secure the mechanism.
See Fig. 1
2. Insert the Left Back Cushion© Middle
Back Cushion© and right Back cushion!El
onto the unit.
3. Engage the Metal Locks and push
fit. You should hear them lock into
position.
See Fig. 2
4. Locate the Velcro on the flap of the
Back Cushions onto the back of
Seat Cushions.
See Fig. 2
.&.
CAUTION:
DO NOT ALLOW CHILDREN TO PLAY
ON THIS MECHANIZED FURNITURE
OR OPERATE THE MECHANISM.
LARGEST FOLDS DOWN ON CLOSI­
NG SO THAT A CHILD COULE NOT
POSSIBLY BE INJURED. ALWAYS
LEAVE IN AN UPRIGHT AND CLOS­
EN POSITION. KEEP HANDS AND
FEET CLEAR OF MECHANISM.
ONLY OCCUPANT SHOULD
OPERATE IT.
®
®
Stage2-Fitting the Unit
Back and Foot Rest Adjustment
This Chair features a reclining back
rest and raised foot rest. You need
to be sitting in the chair to activate
the features.
1. Pull the "Adjustment Lever" and
gently lean back and the chair will
recline and the foot rest will
automatically lift up.
See fig. 3
2. Pull the "Adjustment Lever" again
and lean forward, the back rest
will move forward and the foot rest
will lower.
See fig.
3
3. Adjust the recliner to your own
requirements.
NOTE: It would be useful ask
someone to help you at this
stage.
4. Finally carefully place the unit in
the desired location.
See fig. 4
Fig.
Care and Maintenance
Safety
To avoid any risk of suffocation to animals or children dispose of the plastic bags immediately.
Cleaning
As with all surfaces clean with a damp cloth and mild detergent,do not use bleach or abrasive
products.
Fitting
Fig. 2
From time to time please ensure there are no loose screws on the product.
Adjustment
Level
Fig. 3
Adjustment
Level
Fig. 4
