Model 80575B Trimmer to Brushcutter Conversion Kit
1
18
2
14
13
11
12
P/N X7672231900
MODEL 80575B TRIMMER TO BRUSHCUTTER CONVERSION KIT
10
9
6
8
16
7
17
19
5
4
3
15
NO.
PART NUMBER
QTY. DESCRIPTION
1
C405000420
1
2
90030020022
10
3
90051300010
1
4
C535000150
1
5
61031307132
1
6
P021050520
1
7
V805000170
3
8
C552000240
1
9
C550000770
1
10
90056250005
3
11
C646000060
1
12
V805000140
1
13
C062000390
1
14
C644000080
1
15
C649000200
1
16
X605000060
1
17
X605000100
1
18
X505005890
1
19
61031507130
1
- 1 -
INSTRUCTION SHEET
BAR, BARRIER
PIN, COTTER 2×22
NUT 10×1.25 LH
PLATE, ADAPTER - LOWER
PLATE, ADAPTER - UPPER
DEBRIS SHIELD KIT - BLADE
+BOLT, TORX 5×25
+PLATE, SHIELD
+SHIELD, DEBRIS - BLADE
+NUT, LOCK M5
HANGER, HARNESS
BOLT, TORX 5×12
HARNESS ASSY, SHOULDER
+PAD, SHOULDER
+HOOK, SNAP
WRENCH, T27 80×30
WRENCH, ALLEN 4 MM
LABEL, CAUTION (BLADE CAPABLE)
SPACER 11.8×15×9
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Shindaiwa 80575B
Summary of Contents for Shindaiwa 80575B
- Page 1 INSTRUCTION SHEET MODEL 80575B TRIMMER TO BRUSHCUTTER CONVERSION KIT Model 80575B Trimmer to Brushcutter Conversion Kit PART NUMBER QTY. DESCRIPTION C405000420 BAR, BARRIER 90030020022 PIN, COTTER 2×22 90051300010 NUT 10×1.25 LH C535000150 PLATE, ADAPTER - LOWER 61031307132 PLATE, ADAPTER - UPPER...
- Page 2 Introduction 3. Turn line head (C) clockwise to remove it from the shaft. Remove the locking tool. These are instructions to convert a grass trimmer to a blade capable unit. This is not an Owner’s/Operator’s manual. Information on how to operate and maintain the unit can be found in the Owner’s/Operator’s man- ual for the unit you are converting.
- Page 3 One Bolt Gear Case (gear case ratio 1.62:1) Remove The Handle Assembly Install The Harness Hangar 1. Slide harness hangar (J) onto main pipe (K) and position as shown. Loosely secure the hangar with one 5 x 12 Torx® bolt. Two Bolt Gear Case (gear case ratio 1.57:1) P/N X7672231900 - 3 -...
- Page 4 Install The Handle Assembly With The Barrier Two Bolt Gear Case (gear case ratio 1.57:1) Blade Assembly CAUTION Always install the debris shield. Operating the unit without the debris shield installed can re- Install The Gear Case sult in serious personal injury. 1.
- Page 5 Assemble As Shown: One Bolt Gear Case (gear case ratio 1.62:1) The models listed below require the use of the spacer (reference No. 6) Models Serial Number Range T235 T46714008001 and up T235 T88913001001 and up T262 All T262 models PART NUMBER QTY.
- Page 6 Assemble As Shown: Two Bolt Gear Case (gear case ratio 1.57:1) Models Serial Number Range Models with serial number prefix S955, S956, S957, T235 and T762. T254 All T254 models. T344 All T344 models. PART NUMBER QTY. DESCRIPTION 90030020022 PIN, COTTER 2×22 90051300010 NUT 10×1.25 LH C535000150...
- Page 7 Balance The Unit Adjust the postion of the harness hangar so the unit balances two to three inches above the cutting surface. Use of the Shoulder/Waist Harness is recommended for all Trimmer/Brushcutter use, not just Blade oper- ation. The Shoulder/Waist Harness when used in a trimming operation with nylon line head suspends the trimmer from the operator’s shoulder and reduces op- erator fatigue.
- Page 8 P/N X7672231900 - 8 -...
