3.3 Technical specifications Depth of the frame unit: see table A below
Support profile, base rails
All other profiles
Accessories
Back plate
SolRec base plate

3.4 Operating conditions

Application range
Roof pitch
PV module
Roof construction
Permissible roof load
Attachment method
Triangle and support rails
Max. row length
Distance between the triangles

Planning of the module field

4.1 Dimensions

In the following, the dimensions of the mounting system
will be given. The exact spacing between the triangles is
project-specific and must be individually defined in the
planning phase. Width of the unit: Number of horizontal
modules x (module width + 19) + 31mm; maximum 12 m
e
Portrait installation
|
8
Extruded aluminium (EN AW 6063 T66)
Aluminium (EN AW 6060 T6)
Stainless steel (V2A)
Aluminium (EN AW 5005)
PE
Flat roof
0 — 5°, greater pitch subject to prior verification
Framed, unframed
The suitability of the entire roof construction, in particular at the load transfer points of
the mounting system, must be examined for static, insulation, leak tightness, and fire
protection requirements prior to installation of the PV system.
Must be specifically checked for each project.
Must be specifically checked for each project.
Up to 1,900 PA for a 2.5 m
12 m
Depending on project planning, portrait installation up to approx. 1.5 m,
landscape installation up to approx. 1.8 m
j
h
f
2
surface per triangle and a roof pitch up to 5°
i
Notice:
The material expansion of a 12 m-row
can be approx. 2 cm. Therefore, a minimum
distance of 10 cm between the rows is recom-
mended. Furthermore, for large systems, it is
wise to leave more space at regular intervals
as maintenance paths.
b
g
a
