TECHNICAL DATA
& SERVICE MANUAL
OUTDOOR UNIT:
GR9FI30R5IAA
SPLIT SYSTEM AIR CONDITIONER
Model No.
Product Code No.
GR9FI30R5IAA
387107105
0.8180.626.00
09/2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GR9FI30R5IAA and is the answer not in the manual?

Questions and answers

Summary of Contents for Technibel GR9FI30R5IAA

  • Page 1 TECHNICAL DATA & SERVICE MANUAL OUTDOOR UNIT: GR9FI30R5IAA SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. GR9FI30R5IAA 387107105 0.8180.626.00 09/2012...
  • Page 2 IMPORTANT! • Ground the unit following local electrical codes. • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
  • Page 3: Table Of Contents

    Table of Contents Page 1. OPERATING RANGE 2. SPECIFICATIONS 2-1 Unit specifications 2-2 Major Component specifications 2-3 Other Component specifications 3. DIMENSIONAL DATA 4. REFRIGERANT FLOW DIAGRAM 5. PERFORMANCE DATA 5-1 Performance Charts 6. ELECTRICAL DATA 6-1 Electrical characteristics 6-2 Electric Wiring Diagram 6-3 System Wiring Diagram 7.
  • Page 4: Operating Range

    1. OPERATING RANGE GR9FI30R5IAA Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp. Maximum 32°C D.B. / 23°C W.B. 43°C D.B. Cooling Minimum 10°C D.B. / 6°C W.B. -15°C D.B. Maximum 27°C D.B. 24°C D.B. / 18°C W.B. Heating Minimum 5°C D.B.
  • Page 5: Specifications

    2. SPECIFICATIONS 2-1 Unit Specifications GR9FI30R5IAA 220 - 240V ~ 50Hz Power source 230V Voltage rating Performance * GR9FI30R5IAA Cooling Heating mta8fia0r5i/k2fafia0r5i/kpa8fia0r5i/ca8fia0r5i/sda8fia0r5i 2,65 2,75 Capacity 9037 9378 BTU/h Air circulation (High) m³/h Moisture removal (High) Liters/h Cooling Heating Electrical Rating...
  • Page 6: Major Component Specifications

    2-2 Major Component Specifications Outdoor Unit: GR9FI30R5IAA Compressor Rotary (Hermetic) DC inverter Type 5RS102XBE01 Compressor model Nominal input (compressor rating condition) FV50S …… 320 Compressor oil…Amount Ω N.A. Coil resistance (Ambient temp. 20°C) software protection Overload relay Safety devices Type Operating Temp.
  • Page 7: Other Component Specifications

    2-3 Other Component Specifications GR9FI30R5IAA 4-way Valve (20S) SQ-136 (Coil) SHF-4H-23U (Valve) Coil rating AC 220/240 V, 50 Hz, 6W Ω (at 20°C) Coil resistance 1440 ± 7% ZCAM-MD12EX(Coil) ZCAM-BD15EX (Valve) Electr. Expansion Valve DC 12V Coil rating Ω (at 20°C) 46 ±...
  • Page 8: Dimensional Data

    3. DIMENSIONAL DATA GR9FI30R5IAA 4 – ø12 holes Air intake Wide tube service valve ø9.52 (3/8") 7000/9000 BTU/h ø12.7 (1/2") 12000 BTU/h Narrow tube service valve Air discharge ø6.35 (1/4") Unit : mm...
  • Page 9: Refrigerant Flow Diagram

    4. REFRIGERANT FLOW DIAGRAM Indoor Unit: Outdoor Unit: GR9FI30R5IAA mta8fia0r5i/k2fafia0r5i/kpa8fia0r5i/ca8fia0r5i/sda8fia0r5i Insulation of Refrigerant Tubing IMPORTANT Because capillary tubing is used in the outdoor unit, both the wide and narrow tubes of this air conditioner become cold. To prevent heat loss and wet floors due to dripping of condensation, both tubes must be well insulated with a proper insulation material.
  • Page 10: Performance Data

    5. PERFORMANCE DATA 5-1 Performance charts GR9FI30R5IAA Cooling Characteristics Heating Characteristics Indoor inlet air D.B. (°C) Indoor inlet air D.B. (°C) Outdoor inlet air D.B. temp. (°C) Outdoor inlet D.B. temp. (°C) 34,0 33,0 32,0 Indoor inlet air D.B. (°C)
  • Page 11: Electrical Data

    6. ELECTRICAL DATA 6-1 Electrical characteristics GR9FI30R5IAA OUTDOOR UNIT: COOLING Indoor Unit Outdoor unit Complete Unit Fan Motor Fan Motor + compressor performance at 230V 1-Phase 50 Hz Rating conditions Running Amps. 0,13 2,97 Power input 0,031 0,639 0,670 Rating Conditions: Indoor Air Temperature 27°C D.B.
  • Page 12: Electric Wiring Diagram

    6-2 Electric Wiring Diagram 6-3 System Wiring Diagram...
  • Page 13: Function

    7. FUNCTION 7-1 Diagnostic With this feature is possible to have a visual signal that a trouble is occurring. This mode is always active and the signalling is made through the display board LEDS . In case of no troubles the LEDS status follows its normal function. The detected troubles are showed to the user/technician using the 3 or 5 leds of the indoor unit receiver and the 5 leds on the outdoor pcb.
  • Page 14 R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
