- Page 1 TECHNICAL DATA & SERVICE MANUAL iSeries OUTDOOR UNIT: GR9FI30LTR5IAA GR9FI40LTR5IAA GR9FI50LTR5IAA SPLIT SYSTEM AIR CONDITIONER AEI1G 30 LT AEI1G 40-50 LT GR9FI30LTR5IAA GR9FI4-50 0LTR5IAA May 2016...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SCOPE ........................... 4 DIMENSIONAL DATA AND EXTERIOR APPEARANCE........... 5 TECHNICAL SPECIFICATIONS ..................7 REFRIGERANT CIRCUIT ....................10 ELECTRICAL WIRING DIAGRAM ................13 PRINCIPLE OF FUNCTIONING................... 15 COMPONENTS OPERATION..................17 DEFROST..........................19 PROTECTIONS ......................... 21 COMPONENT DESCRIPTION ..................23 DIAGNOSTIC TABLE ...................... - Page 3 REVISION NOTES Rev. Date Author Checked Comments 01/10/2014 First release. 30-40-50 14/11/2014 Added Scope, Packaging and Labels sections. Added 20/01/2015 exterior appearance description. Fixed CDT sensor table.
-
Page 4: Scope
1 Scope This specification document is applied to the outdoor units mentioned below used for air to air heat pump to be delivered UNIT MODEL TABLE CODICE TECHNIBEL GR9FI30LTR5IAA 387107115 GR9FI40LTR5IAA 387107116 GR9FI50LTR5IAA 387107117 DECLARATION OF CONFORMITY “CE” Units described in this document conform to the protection requirement of the following EC directives: •... -
Page 5: Dimensional Data And Exterior Appearance
2 Dimensional data and exterior appearance GR9FI30LTR5IAA Exterior appearance – color Top/front and side/rear panel: silver (F1936) Fan Guard and valve covering: gray (RAL7042) Material Panel: zinc-coated steel sheet Fan guard and valve covering: polypropylene Painting 2 layers, 20 µ or more for electro coating (lower layer) 40 µ... - Page 6 GR9FI40LTR5IAA GR9FI50LTR5IAA Exterior appearance – color Top/front and side panel: silver (F1936) Fan Guard and valve covering: gray (RAL7042) Material Panel: zinc-coated steel sheet Fan guard and valve covering: polypropylene Painting 2 layers, 20 µ or more for electro coating (lower layer) 40 µ...
-
Page 7: Technical Specifications
3 Technical specifications GR9FI30LTR5IAA COOLING Pdesignc 2680 +35°C SEER 6,11 HEATING Pdesignh 3030 Average -10°C SCOP 3,82 ERP Ecodesign - EN14825 COOLING Minimum 1370 +35°C OU / 27/19°C IU Maximum 3650 HEATING Minimum +7/6°C OU / +20°C IU Maximum 3880 -7°C/-8°C OU / + 20°... - Page 8 GR9FI50LTR5IAA COOLING Pdesignc 3670 +35°C SEER 6,06 HEATING Pdesignh 4020 Average -10°C SCOP 4,01 ERP Ecodesign - EN14825 COOLING Minimum 1010 +35°C OU / 27/19°C IU Maximum 4060 HEATING Minimum +7/6°C OU / +20°C IU Maximum 4870 -7°C/-8°C OU / + 20° C IU Maximum 3510 -10°C/-11°C OU / + 20°...
- Page 9 GR9FI50LTR5IAA COOLING Pdesignc 5215 +35°C SEER 6,74 HEATING Pdesignh 4070 Average -10°C SCOP 4,16 ERP Ecodesign - EN14825 COOLING Minimum +35°C OU / 27/19°C IU Maximum 5650 HEATING Minimum 1030 +7/6°C OU / +20°C IU Maximum 5290 -7°C/-8°C OU / + 20° C IU Maximum 3900 -10°C/-11°C OU / + 20°...
-
Page 10: Refrigerant Circuit
4 Refrigerant circuit GR9FI30LTR5IAA Note: In heating mode the refrigerant flow is in the opposite direction of the COOL arrows INV: 4-way valve EXP: Electronic Expansion Valve COM: Compressor... - Page 11 GR9FI40LTR5IAA Note: In heating mode the refrigerant flow is in the opposite direction of the COOL arrows INV: 4-way valve EXP: Electronic Expansion Valve COM: Compressor...
- Page 12 GR9FI50LTR5IAA Note: In heating mode the refrigerant flow is in the opposite direction of the COOL arrows INV: 4-way valve EXP: Electronic Expansion Valve COM: Compressor...
-
Page 13: Electrical Wiring Diagram
5 Electrical wiring diagram Legend Control pcb Outdoor Air Sensor Main fuse Compressor Discharge Sensor 6,3x32 - 10A / 250V Comm. Fuse, RS485 bus cable Outdoor Coil Sensor 5x20 - 100mA / 250V Dip-switch Electronic Expansion Valve JP1/2/3 Jumpers Crankcase Heater Electromagnetic Interference Drip tray heater Filter... - Page 14 Settings Jumpers JP1: Factory use. Default: open. JP2: Defrost type selection. Default: closed. JP3: Heating only option. Default: open (heating and cooling). Dip-switch: SW1: Factory use. Default: 1=Off, 2=Off. Note: Jumper and dip-switch settings can be changed only when unit is powered off.
-
Page 15: Principle Of Functioning
6 Principle of functioning Heating mode When the unit is in heating mode, the system will regulate the heating capacity delivered to the room to increase the room air temperature (RAT) to the set point (SPT) and to balance the thermal load of the room to keep the set point temperature. - Page 16 Dehumidification (dry) mode When the unit is in dry mode, the system will operate according to the following table: DRY LEVEL DESCRIPTION ≥ SPT + 2°C Unit operates normally in cooling mode. Unit operates with a fixed cooling demand. < SPT + 2°C Indoor fan switches between very low speed and ≥...
-
Page 17: Components Operation
7 Components operation Compressor The compressor runs if the following conditions are met: At least 3 minutes have passed since the power supply was switched on At least 3 minutes have passed since the compressor was stopped At least 6 minutes have passed since the previous compressor start There is no active alarm on the outdoor and indoor units There is no active protection There is a thermal load demand in the room... - Page 18 Crankcase heater Crankcase heater around the compressor is used to prevent refrigerant migration and mixing with crankcase oil when the unit is off, and to prevent condensation of refrigerant in the crankcase of the compressor. The crankcase heater keeps refrigerant at a temperature higher than the coldest part of the system.
-
Page 19: Defrost
8 Defrost A defrost starts if one of these conditions is satisfied (see graph below): - OCT falls below L1 line and compressor is running for at least 35 minutes without defrost - OCT falls below L2 line and compressor is running for at least 60 minutes without defrost A defrost ends if one of these conditions is satisfied: - OCT rise above 14°C and defrost has been active for at least 2 minutes - defrost has been active for 12 minutes... - Page 20 Before reversing the cycle at the beginning and at the end of the defrost, the compressor ramps down to decrease the pressure inside the circuit: When defrost is active: 4-way valve is deactivated Compressor runs at a fixed speed (if no protection is active) EEV is open at a fixed value Fan is off When defrost ends:...
-
Page 21: Protections
9 Protections The unit is equipped with an automatic system of protections. These protections, if active, will limit the speed of the compressor in order to run the system in a safe operating area. Protections, when active, reduce the speed of the compressor linearly down to its minimum speed. If the level of protection is too high, compressor is stopped until no protection will be active. - Page 22 Over power consumption from the power supply This protection checks the power consumption of the outdoor unit (but not of the indoor unit) to avoid an excessive power consumption than can damage the pcb and the unit. This protection is always active and limits the compressor speed to keep the outdoor unit power consumption below 1800W.
-
Page 23: Component Description
10 Component description GR9FI30LTR5IAA GR9FI40LTR5IAA Compressor type HERMETIC, SINGLE ROTARY, DC INVERTER model 5RS102XBE01 RB68A or Freol Alpha 68M refrigerant R410A motor BRUSHLESS MOTOR n. of poles rated output 700 W winding resistance U-V: 0,858 Ω V-W: 0,858 Ω U-W: 0,858 Ω (@20 °C) overload protector CS-7L 115 (WAKO ELECTRIC OR EQUIVALENCE) - Page 24 GR9FI50LTR5IAA Compressor type HERMETIC, TWIN ROTARY, DC INVERTER model SNB130FGBMT FV 50S refrigerant R410A motor BRUSHLESS MOTOR n. of poles rated output 900 W winding resistance U-V: 0,98 Ω V-W: 0,98 Ω U-W: 0,98 Ω (@20 °C) overload protector EXTERNAL Fan Motor model ZW465B57...
- Page 25 Sensors OCT: Outdoor Coil Temperature. Used for: EEV management Fan management Protection against overheating of the heat exchanger (cooling or dry mode) Defrost cycle management (heating mode) OAT: Outdoor Air Temperature. Used for: EEV management Fan management Defrost cycle management Crankcase heater management Base heater management CDT: Compressor Discharge Temperature.
-
Page 26: Diagnostic Table
11 Diagnostic table When unit is working properly: DL3 is solid ON DL4 is solid ON if the indoor unit is switched ON, otherwise it’s OFF... -
Page 27: Troubleshooting
12 Troubleshooting ERROR LIST System Rank Meaning Cause Solution behaviour PFC (Power Factor Compressor and fan Power supply surge or Check the quality of the power Controller) are stopped. over voltage. supply. protection: The system restarts automatic automatically after Power supply voltage protection against 3 minutes. - Page 28 Communication fuses Check the communication fuse on blown. outdoor unit. Check the communication fuse on indoor unit (only certain models). Indoor unit not Check that the indoor unit has power powered on. supply and that the unit is working. Outdoor or indoor unit Check that all the pcbs are powered pcb out of order.
- Page 29 Automatic Compressor and fan Bad connection Check that the outdoor pcb is protection against are stopped.The between the outdoor properly connected to the heatsink overheating on the system restarts pcb and the heatsink. and that the screws on the pcb are power electronics automatically after properly mounted with the right...
-
Page 30: Component Replacement
13 Component replacement GR9FI30LTR5IAA... - Page 31 GR9FI 30-40-50LTR5IAA...
- Page 32 GR9FI30LTR5IAA...
- Page 33 GR9FI30LTR5IAA...
- Page 34 GR9FI30LTR5IAA...
- Page 35 GR9FI40-50 LTR5IAA...
- Page 36 GR9FI40-50 LTR5IAA...
- Page 37 GR9FI40-50 LTR5IAA...
- Page 38 GR9FI40-50 LTR5IAA...
-
Page 39: Packaging
14 Packaging GR9FI30 LTR5IAA 1: bottom carton box 6: upper right PS shield 2: lower left PS shield 7: carton box 3: lower right PS shield 8: staple 4: polietylene sheet 9: scotch tape 5: upper left PS shield 10: PP band... - Page 40 GR9FI40-50 LTR5IAA 1: bottom carton box 6: upper left PS shield 11: PP band 2: lower left PS shield 7: upper right PS shield 3: lower PS shield 8: carton box 4: lower right PS shield 9: staple 5: polietylene sheet 10: scotch tape...
-
Page 41: Labels
15 Labels Energy labels GR9FI30 LTR5IAA... - Page 42 GR9FI40 LTR5IAA...
- Page 43 GR9FI50 LTR5IAA...
- Page 44 Rating labels...
- Page 45 Technibel is a TRADE mark of NIBE ENERGY SYSTEMS FRANCE, used under licence. IMPORTED & DISTRIBUTED BY ARGOCLIMA SPA - Via Alfeno Varo, 35 - Alfianello (BS) Italy...
