- Page 1 Ceramic Glass HOB Installation and Operating Instructions KM60021S To avoid the risk of accidents or damage to the HOB, it is essential to read these operating instructions before it is installed or used for the first time. And please keep this manual for later reference.
- Page 2 Dear Customer Please read these operating instructions carefully. Above all, please observe the “safety” section on the first few pages. Please retain these operating instructions for later reference. Pass them on to any subsequent owners of the appliance. The following symbols are used in the text: Safety information -- Warning: Information concerning your personal safety.
-
Page 3: Table Of Contents
Contents Safety ..................4-7 Suitable Kitchenware .............. 8-9 Description of the appliance ........... 10 Cooking zones and control ............10 The key features of your appliance .........11 Operating Instructions ............. 12 Before using for the first time ........... 12 Operating the hob ..............12 Uses, Tables and Tips .............. -
Page 4: Safety
Safety The safety aspects of this appliance comply with accepted technical standards and IEC Standards. However, as the manufacturer we also believe it is our responsibility to familiarize you with the following safety instructions. Electrical Safety • The installation and connection of the new appliance must only be carried out by qualified personnel. - Page 5 Child Safety WARNING: Accessible parts may become hot during use. Young children should be kept away. This appliance is not intended for use by young children or infirm persons unless they have been adequately supervised by a responsible person to ensure that they can use the appliance safely.
- Page 6 Safety Safety When Cleaning • Always switch off the appliance before cleaning. • For safety reasons do not clean the appliance with a steam jet or high pressure cleaner. • Clean the hob in accordance with the maintenance and cleaning instructions in this manual.
- Page 7 Disposal of old appliances Warning: Before disposing of old appliances please make them inoperable so that they cannot be the source of danger. To do this, have a qualified person disconnect the appliance from the house circuitry. To protect the environment, it is important that worn out appliances are disposed of in the correct manner.
-
Page 8: Suitable Kitchenware
Suitable Kitchenware Pots and pans The better the pot, the better the cooking results. • You can recognize good pots and pans by their bases. The base should be as thick and flat as possible. • When buying new pots and pans, pay particular attention to the diameter of the base. - Page 9 Tips on saving energy You will save valuable energy by observing the following points: • Always position pots and pans before you switch on the cooking zone. • Dirty cooking zones and pot bases increase the power consumption. • Whenever possible, always have the lid firmly placed on the pots and pans so that they are completely covered.
-
Page 10: Description Of The Appliance
Description of the Appliance Cooking zones and control KM 60021S Cooking zone Cooking zone 1800W 19cm 1200W 15cm Cooking zone Cooking zone 1800W 19cm 1200W 15cm Indicators Oven Control panel Oven model : LE621120S Heater control knob Oven model : LE621100S Heater control knob * Heater control knob : Set and adjust the power level. -
Page 11: The Key Features Of Your Appliance
The Key Features of Your Appliance • Cooking zones: The appliance is fitted with ceramic glass. • Easy cleaning: The advantage of the ceramic glass cooking surface is their accessibility for cleaning. The flat surface is easy to clean. • Residual heat indicator: An indicator for residual heat is turned on if the cooking zone becomes so hot that there is a risk of burning. -
Page 12: Operating Instructions
Operating Instructions Before using for the first time Initial Cleaning Wipe the ceramic glass surface with a damp cloth and ceramic cooktop glass cleaner. Important: Do not use any caustic, abrasive cleaners! The surface could be damaged. Operating the hob For setting and adjusting the power level ( ) for cooking, dial the relative cooking zone knob in the oven control panel. -
Page 13: Uses, Tables And Tips
Uses, Tables and Tips Chart for Setting the Cooking Zones Heat setting suitable for Heating Up Bringing liquid to a boil. Heavy Browning meat, heat oil for deep fat Browning frying or sauteing. Deep fat Maintaining fast boil for large frying amounts of liquids. -
Page 14: Cleaning And Care
Cleaning and care Light Soiling 1. Wipe the ceramic glass surface with a damp cloth and a little cooktop cleaner. 2. Then rub dry with a clean cloth. Remnants of cleaner must not be left on the surface. 3. Thoroughly clean the entire ceramic glass cooking surface once a week with a commercially available ceramic glass or stainless steel cleaner. - Page 15 Problem Soils 1. Remove sugar, melted plastic, aluminium foil or other meltable materials with a glass scraper immediately and while still hot. Important: There is a risk of burning yourself when the glass scraper is used on a hot cooking zone! 2.
-
Page 16: Installation Instructions
Installation Instructions Technical Data Important! The new appliance may only be installed and connected by a registered specialist. Please observe these instructions, otherwise the warranty will not cover any damage that may occur. Appliance dimensions Width 575mm Depth 515mm Height 40mm Worktop cut-out dimensions Width... -
Page 17: Regulations, Standards, Directives
Regulations, Standards, Directives This appliance meets the following standards: • EN 60335-1 and EN 60335-2-6 relating to the safety of electrical appliances for household use and similar purposes and • EN 60350 Methods for measuring performance. • EN 55014-2 • EN 55014-1 •... -
Page 18: Safety Instructions For The Installer
Installation Instructions Safety Instructions for the Installer • A device must be provided in the electrical installation which allows the appliance to be disconnected from the mains at all poles with a contact opening width of at least 3 mm Suitable isolation devices include line protecting cut-outs, fuses (screw type fuses are to be removed from the holder), earth leakage trips and contactors. -
Page 19: Electrical Connection
Electrical Connection Before connecting, check that the nominal voltage of the appliance, that is the voltage stated on the rating plate, corresponds to the available supply voltage. The rating plate is located on the lower casing of the hob. Shut off power to circuit before connecting hob wires to circuit. The heating element voltage is AC230V~. -
Page 20: Assembly
Installation Instructions Assembly Bracing <Fig. 1> Remove the bracing from the Furniture furniture for hob airflow. min. 50 mm <Fig. 2> min. 50 mm min. 50 mm min. 5 mm Follow Fig.2 for minimum required surface clearances. - Page 21 <Fig. 3> Cabinet cutout and mounting clip locations.
- Page 22 Installation Instructions <Fig. 4> Caution: It is important to keep 20 mm distance between hob case and combustible surface. Make sure hob is fully seated, with foam tape compressed against countertop. <Fig. 5> To remove the hob, it must be pressed out from below.
-
Page 23: Troubleshooting
Troubleshooting Malfunctions often have simple explanations. Please read the following instructions before calling the after-sales service: Problem description Possible cause or Remedies Hob does not work. • Check below. – Connection and Main Switch. – The correponding cooking zone is selected. -
Page 24: Service
Service Packaging and old appliances Your new appliance was protected by suitable packaging while it was on its way to you. All materials used for this purpose are environmentally friendly and can be recycled. Please make a contribution to protecting the environment by disposing of the packaging appropriately. - Page 25 Memo...
- Page 26 Memo...
- Page 28 FOR WARRANTY SERVICE PLEASE CONTACT THE RETAILER FROM WHOM YOU PURCHASED YOUR UNIT OR CONTACT LG SERVICE LG ELECTRONICS S.A.(Pty) Ltd. P.O.BOX 473 ISANDO 1600 LG Service center Phone: 0800-LGLGLG (0800-545454) http://za.lge.com...
