Assembly Instructions
For more information contact our team: service.ec@foagroup.com
CM3163BN
ASSEMBLY RATING
Tools Required For Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
Allen Wrench
easy and 5 being difficult). For some
(Included)
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 5
Rev: 2018-07-05
Advertisement
Related Manuals for Furniture of America CM3163BN
Summary of Contents for Furniture of America CM3163BN
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3163BN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 10pcs Seat Frame Bolt Ø1/4" x 2-1/2" #2 x 2pcs #B x 10pcs Leg L/R Lock Washer Ø1/4"...
- Page 4 Prepare 2 bolts assembly by inserting washer (#B) onto bolts (#A). Align center stretcher (#3) to the holes of the legs (#2L/R). Secure with bolts (#A). #A x 2pcs #B x 2pcs #A x 8pcs #B x 8pcs #C x 8pcs Prepare 8 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A).
- Page 5 Place cover (#4) to each center holes of the legs (#2L/R). ASSEMBLY IS COMPLETED Page 5 of 5...
