- Page 1 USE AND MAINTENANCE MANUAL FM1500 S FM1500 V ED. 10-2010 ORIGINAL INSTRUCTIONS Doc. 10026345 Ver.
- Page 2 The descriptions contained in this document are not binding. The company therefore reserves the right to make any modifications at any time to elements, details, or accessory supply, as considered necessary for reasons of improvement or manufacturing/commercial requirements. The reproduction, even partial, of the text and drawings contained in this document is prohibited by law.
-
Page 3: Table Of Contents
13. REAR - SIDE WHEEL ADJUSTMENT ..............................12 TROUBLESHOOTING..................................13 14. THERMAL CUT-OUT..................................13 15. THE MACHINE VIBRATES OR OSCILLATES............................13 16. MOTOR BRUSH WEAR INDICATOR ..............................13 DISPOSAL .....................................14 FM1500 S-V ELECTRICAL SYSTEM DIAGRAM ..........................15 EC DECLARATION OF COMPLIANCE ............................16... -
Page 4: On Consignment Of The Machine
The machine is only suitable for use in closed - or at least FM1500 S and FM1500 V machines are built for the professional covered - locations. The machine is not suitable for use in the rain, or cleaning of hard and vinyl floors for indoor surfaces, to be carried out by under water jets. -
Page 5: Symbols Used On The Machine
SYMBOLS USED ON THE MACHINE Indicates the earth connection point of the electric system of the machine Voltage symbol Warning high voltage 230 Volt Indicates the maximum gradient... -
Page 6: General Safety Regulations
• When your FIMAP machine has reached the end of its long working life, dispose of the materials it contains (especially oils and electronic components) in an appropriate manner, while taking into account that the machine itself was constructed by using 100% recyclable materials. -
Page 7: Machine Preparation
The machine is contained in specific packaging with a pallet for the handling with fork trucks. The packages CANNOT be placed on top of each other. The total mass of the packed machine is 38 kg The package dimensions are as follows: FM1500 S-V A : 1230 mm B: 580 mm C: 690 mm 2. -
Page 8: Handlebar Adjustment - Work Position
MACHINE PREPARATION 3. Man present push-button 6. HANDLEBAR ADJUSTMENT – WORK POSITION Before you start working with the machine, you will need to find the correct work position. To do this, press the tilt adjustment lever, release it until your arms are slightly bent and as low as possible, while keeping the back straight and the legs slightly apart. -
Page 9: Work
WORK 9. PREPARING TO WORK Make sure the power supply cable is not damaged Plug the power supply cable of the machine into the mains socket Bring the handlebar into work position by acting on the release lever 10. MANOEUVRABILITY OF THE MACHINE The first time an operator uses the machine, he/she should become familiar with the movements to be imparted to the shaft in order to be confident enough with the directionality of movement of the machine, and should therefore not operate the machine near people or obstacles. -
Page 10: At The End Of The Work
AT THE END OF THE WORK At the end of the work, and before carrying out any type of maintenance, perform the following operations: Disconnect the plug from the mains socket Wrap it onto the rear brackets Operate the handlebar adjustment lever (1) and set the column at rest Move the machine indoors, in an area where it cannot cause any damage to people or surrounding property, but where it can also be protected against the accidental fall of objects. -
Page 11: Daily Maintenance
DAILY MAINTENANCE PERFORM ALL MAINTENANCE OPERATIONS IN SEQUENCE 12. DISASSEMBLING THE BRUSHES-PAD HOLDER 7. Make sure the power supply cable is unplugged from the mains socket 8. Check that the handlebars are in the rest position 9. Tilt the machine until bringing the handlebars down to the ground, by putting a foot into the rear of the base body WARNING: This operation must be carried out using gloves to protect against contact with dangerous solutions. -
Page 12: Periodic Maintenance
13. REAR - SIDE WHEEL ADJUSTMENT Check the rear (1) and side (2) wheels adjustment to ensure the machine works perfectly. WARNING: Have the rear and side wheels adjusted by a FIMAP qualified technician to avoid irreparable damages to the machine. -
Page 13: Troubleshooting
16. MOTOR BRUSH WEAR INDICATOR The machine is provided with a red warning light which indicates the base motor brushes are worn out. When it is on contact a FIMAP technician as soon as possible to replace the brushes. -
Page 14: Disposal
DISPOSAL To dispose of the machine, take it to a demolition centre or an authorised collection centre. Before scrapping the machine, it is necessary to remove and separate the following materials and then send them to the appropriate collection centres, in accordance with the currently effective environmental hygiene regulations: •... -
Page 15: Fm1500 S-V Electrical System Diagram
FM1500 S-V ELECTRICAL SYSTEM DIAGRAM GNYE GNYE GNYE GNYE COMPONENT NAMES CABLE NAMES ABBR CABLE Cut-out 10A Cable 3x1.5x15 metres + shuko plug -1- Black Operating switch 16A Cable 3x1.5x1600 -2- Blue Network filter Brown cable 1.5x150 -3- Brown Rectifier Yellow/green cable 1.5x140 -5-... -
Page 16: Ec Declaration Of Compliance
37059 Santa Maria di Zevio (VR) - ITALY Santa Maria di Zevio, 21/10/2010 FIMAP S.p.A. Legal representative Giancarlo Ruffo FIMAP spa Via Invalidi del Lavoro, 1 - 37050 S.Maria di Zevio (Verona) Italy Tel. +39 045 6060411 r.a. - Fax +39 045 6060417 - E-mail:fimap@fimap.com - www.fimap.com...
