Panasonic Corporation
Web Site: http://panasonic.net
IP5038_3BN00PT_Cov_01_140910.indd 1
IP5038_3BN00PT_Cov_01_140910.indd 1
F0003BN00PT
IP1014-0
Model No. NN-GF574M
Before operating this oven, please read these instructions completely and keep for future reference.
.‫ﻗﺒﻞ ﺍﺯ ﺍﺳﺘﻔﺎﺩﻩ ﺍﺯ ﺍﻳﻦ ﺩﺳﺘﮕﺎﻩ، ﻟﻄﻔﺎ ﻣﻄﺎﻟﺐ ﺍﻳﻦ ﺩﻓﺘﺮﭼﻪ ﺭﺍ ﺑﻪ ﻃﻮﺭ ﻛﺎﻣﻞ ﺑﺨﻮﺍﻧﻴﺪ ﻭ ﺁﻥ ﺭﺍ ﺑﺮ ﺍﻯ ﻣﺮﺍﺟﻌﻪ ﺩﺭ ﺁﻳﻨﺪﻩ ﻧﺰﺩ ﺧﻮﺩ ﻧﮕﻬﺪﺍﺭﻳﺪ‬
Operating Instructions
‫ﺩﻓﺘﺮﭼﻪ ﺭﺍﻫﻨﻤﺎ‬
Microwave/Grill Oven
‫ﺍﺟﺎﻕ ﻣﺎﻳﻜﺮﻭﻭﻳﻮ/ﻛﺒﺎﺏ ﭘﺰ‬
Household Use Only
‫ﻓﻘﻂ ﺍﺳﺘﻔﺎﺩﻩ ﺧﺎﻧﮕﯽ‬
2014/9/10 16:14:54
2014/9/10 16:14:54

Advertisement

Table of Contents
loading

Related Manuals for Panasonic NN-GF574M

Summary of Contents for Panasonic NN-GF574M

  • Page 1 Microwave/Grill Oven ‫ﺍﺟﺎﻕ ﻣﺎﻳﻜﺮﻭﻭﻳﻮ/ﻛﺒﺎﺏ ﭘﺰ‬ Household Use Only ‫ﻓﻘﻂ ﺍﺳﺘﻔﺎﺩﻩ ﺧﺎﻧﮕﯽ‬ Panasonic Corporation Model No. NN-GF574M Web Site: http://panasonic.net F0003BN00PT Before operating this oven, please read these instructions completely and keep for future reference. IP1014-0 .‫ﻗﺒﻞ ﺍﺯ ﺍﺳﺘﻔﺎﺩﻩ ﺍﺯ ﺍﻳﻦ ﺩﺳﺘﮕﺎﻩ، ﻟﻄﻔﺎ ﻣﻄﺎﻟﺐ ﺍﻳﻦ ﺩﻓﺘﺮﭼﻪ ﺭﺍ ﺑﻪ ﻃﻮﺭ ﻛﺎﻣﻞ ﺑﺨﻮﺍﻧﻴﺪ ﻭ ﺁﻥ ﺭﺍ ﺑﺮ ﺍﻯ ﻣﺮﺍﺟﻌﻪ ﺩﺭ ﺁﻳﻨﺪﻩ ﻧﺰﺩ ﺧﻮﺩ ﻧﮕﻬﺪﺍﺭﻳﺪ‬...

  • Page 2: Table Of Contents

    Timer Setting (Kitchen Timer/Standing Time/Delay Time) ......................19 Before Requesting Service .................................20 Care of your Microwave Oven ..............................21 Technical Specifications ................................21 Quick Guide ....................................22 © Panasonic Appliances Microwave Oven (Shanghai) Co., Ltd. 2014 - Eng-1 - IP5038_3BN00PT_Eng_12_141029.indd 1 IP5038_3BN00PT_Eng_12_141029.indd 1 2014-10-29 11:40:33...

  • Page 3: Important Safety Instructions

    Important Safety Instructions READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Precautions to be taken when Important Instructions using Microwave Ovens for Heating WARNING—To reduce the risk of burns, electric shock, fire, injury to persons or excessive microwave energy: Foodstuffs 1. Read all instructions before using microwave oven. Inspection for Damage: 2.

  • Page 4: Installation And General Instructions

    Installation and General Instructions General Use (b) Do not place oven near a hot or damp surface such as a gas stove, electric range or sink etc. 1. In order to maintain high quality, do not operate the (c) Do not operate oven when room humidity is too high. oven when empty.

  • Page 5: Feature Diagram

    Feature Diagram Flat Table 1. If the flat table is hot, allow cooling down before cleaning. 2. Do not cook directly on the flat table. Always put the food in the container or rack. Oven Air Vent Grill Elements Caution Label Door Safety Lock System Warning Label Oven Air Vent...

  • Page 6: Control Panel

    Control Panel (1) Display Window (2) Time Pads (3) Micro Power Pad (4) Grill Pad (5) Combination Pad (6) Turbo Defrost Pad (7) Timer/Clock Pad (8) Auto Cook Menu Pads (9) Weight Pads (10) Stop/Reset Pad Before Cooking: One tap clears your instructions.

  • Page 7: Display Window

    Display Window To help you operate the oven conveniently, the present state will appear in the Display Window. Number Power Level (Time/Weight/Menu Number) Child Safety Lock Setting Weight Timer (Second) Stage Display Wire Rack Timer (Minute) Defrost Microwave Power Grill Clock Setting You can use the oven without setting the clock.

  • Page 8: To Reheat/Defrost/Cook By Setting Power And Time

    To Reheat/Defrost/Cook by Setting Power and Time This feature allows you to set the desired power and time for cooking by yourself. 1. Put the food into the oven 2. Select Microwave Power Level Press Micro Power Pad until the desired power level appears in the Display Window.

  • Page 9: To Defrost

    To Defrost Turbo Defrost This feature allows you to defrost meat, poultry and seafood by weight. Weight must be programmed in kilograms. 1. Put the food into the oven Appropriate type of food for Turbo Defrost Meat loaf, chicken, rib Beef, lamb, whole chicken Whole fish, shellfish, prawn and fish fillet 2.

  • Page 10: Defrosting Tips And Techniques

    Defrosting Tips and Techniques Preparation for Freezing The quality of the cooked foods comes from the foods before wrap and the meat which has been sealed before selling are freezing, freezing ways and defrosting tips and times. So it all able to be reserved in the refrigerator for some times. is important to purchase fresh and high quality foods.

  • Page 11: To Cook On Grill By Time Setting

    To Cook on Grill by Time Setting There are three grill setting modes. (1 - High, 2 - Medium, 3 - Low) Directions for Grill Cooking: There are three power levels for grill. When grilling, heat is radiated from the two quartz tubes at the top of the oven. The oven door must be kept closed to prevent cooking odours from spreading in the kitchen and so as not to waste energy.

  • Page 12: To Cook On Combination By Time Setting

    To Cook on Combination by Time Setting There are three combination setting modes. Directions for Combination Cooking: There are three power levels for combination. It's a good way for roasting foods by combining microwave and grill effectively. It's suitable for roasting poultry, meat and seafood. This function can ensure the foods even cooking and keep the crispness of certain foods.

  • Page 13: 3-Stage Setting

    3-Stage Setting This feature allows you to program 2-3 Stages of cooking continuously. Example: Continually set [Medium power] 2 minutes, [Combination 1] 3 minutes and [Grill 2] 2 minutes. twice 3 times 1. Press 3 times. 2. Press twice. 3. Press once. 4.

  • Page 14: Auto Cook Setting

    Auto Cook Setting This feature allows you to set some ordinary menus with different weights. It will cook automatically without setting power and time. Select the category of food and then just enter the weight. Do not include the weight of any added water or the container weight.

  • Page 15: Auto Cook Menus

    Auto Cook Menus Combi Crispy Menu Recommended Menu Weight Number Containers Reheat Chilled Pizza 100 g 200 g 300 g 400 g wire rack with a dish underneath Reheat Fried Food 200 g 400 g 600 g 800 g 1. Reheat Chilled Pizza It is suitable for reheating chilled pizza.
  • Page 16 Auto Cook Menus (continued) Auto Reheat Menu Recommended Menu Weight Number Containers microwave safe dish Reheat Meal 1 Serv. 2 Serv. 3 Serv. 4 Serv. with a lid or plastic wrap Reheat Bread 100 g 200 g 300 g 500 g microwave safe dish microwave safe dish Frozen Reheat...
  • Page 17 Auto Cook Menus (continued) Vegetables Menu Recommended Menu Weight Number Containers Vegetables 100 g 200 g 300 g 400 g microwave safe container with a lid or Root Vegetables 180 g 250 g 370 g 500 g plastic wrap microwave safe Jacket Potatoes 250 g 370 g...
  • Page 18 Auto Cook Menus (continued) Rice Menu Recommended Menu Weight Number Containers Rice 1 cup 1.5 cups 2 cups 2.5 cups microwave safe container with a lid or Risotto 0.5 cup 1 cup 2 cups 3 cups plastic wrap 19. Rice It is suitable for cooking plain rice.
  • Page 19 Auto Cook Menus (continued) Pasta Menu Recommended Menu Weight Number Containers Pasta 150 g 250 g 350 g 500 g microwave safe container with a lid or Instant Noodle 1 Serv. 2 Serv. plastic wrap 21. Pasta It is suitable for cooking a variety of pastas such as spaghetti, fettuccine, tagliatelle, macaroni, penne, spiral and various pasta shapes.

  • Page 20: Timer Setting (Kitchen Timer/Standing Time/Delay Time)

    Timer Setting (Kitchen Timer/Standing Time/Delay Time) This feature allows you to program the oven as a kitchen timer. It can be also used to program a stand time after cooking is completed or to program a delay start. To use as a Kitchen Timer: Example: To count 5 minutes 5 times 1.

  • Page 21: Before Requesting Service

    Before Requesting Service ALL THESE THINGS ARE NORMAL: The oven causes interference Some radio and TV interference might occur when you cook with the microwave oven. with my TV. This interference is similar to the interference caused by small appliances such as mixers, vacuums, hair dryers, etc.

  • Page 22: Care Of Your Microwave Oven

    Care of your Microwave Oven 1. The oven should be cleaned regularly and any food 9. After GRILL or COMBINATION cooking the ceiling deposits removed. and walls of the oven should be cleaned with asoft 2. Turn the oven off and remove the power plug from the cloth squeezed in soapy water.

  • Page 23: Quick Guide

    Quick Guide Feature How to Operate To Set Clock page 6) Press twice. Set time of day. Press once. To Set: To Cancel: Display Display To Set/Cancel Child Safety Lock page 6) Press 3 times. Press 3 times. To Cook/Reheat/Defrost by Micro Power and Time Setting page 7)
