- Page 1 Indoor Building Entrance ™ Terminal (IBET) 4588VTP, 4588VSTP, 4588VTPC and 4588VSTPC Series with 3M Quick Connect System (QCS) 2811 Dry ™ Flame-Retardant Block Instructions Underwriters Laboratories (UL 348X) Listed May 2012 78-0013-6691-9-A...
- Page 2 Available 4588V-QCS IBETs: VTP, VTPC, VSTP and VSTPC QCS series IBET terminals are available in all cable pair configurations listed below. And are available in both 3M 710 Splicing System SD modules or 3M MS Super Mini Splicing Module 4005-DPM/FR. ™...
- Page 3 4588VTPCand 4588VSTPC. Special Tools Needed to Splice modules or 3M 710 Splicing System ™ 2™ ™ SD Modules (Not required if 3M Scotchlok ™ ™ Connectors are used) Indoor Building Entrance Terminal Location and Mounting ™ Choose a location for the terminal according to your CAUTION...
- Page 4 Insert the gland’s groove into the cable port. Slide the PST over the gland and slowly unwind the core. The PST core fits over either the small diameter of the 25 -to 50-pair gland or butts up against the 3M Indoor ™...
- Page 5 Splicing Splice the feeder cable group(s) to the appropriate 3M Terminal Block Tail(s) per your company’s practice. ™ Bundle completed 3M Splice Module(s) and secure them with 3M Cable Ties within the splice chamber. ™ ™ Close the splice chamber cover and secure the lock plate bolt.
- Page 6 Installing the Electrical Protectors Note: Use ONLY UL Recognized or Listed protectors in the 3M Indoor Building Entrance ™ Terminal (IBET). The 3M Indoor Building Entrance Terminal (IBET) ™ 4588V Series uses a standard five pin protector receptacle field. The long pins of the protector...
- Page 7 10.0 3M Priority Caps ™ 10.1 Priority caps are used to designate special purpose circuits and prevent entry of the 3M Single Pair Test ™ Probe. 10.2 To install priority caps, place over the jumper cap of the pair to be marked and push it into place. Latching is indicated by an audible snap.
- Page 8 Warranty; Limited Remedy; Limited Liability. This product will be free from defects in material and manufacture for a period of one (1) year from the time of purchase. 3M MAKES NO OTHER WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
