- Page 1 User’s manual Please read this manual carefully before operating your TV set and retain it for further reference. HL66V88 HL81V88 Model Number: Part Number: IES090339 Http://www.hisense.com.au...
- Page 2 Hisense and/or its Agents will decide if there are any defects in the manufacturing processes involved and are usually not noticeable...
- Page 3 If a claim is made that is found not to be covered under this warranty, or no faulty hardware components are found, you will be charged at Hisense or Hisense Authorised Service Center's standard service charge plus an administration fee.
- Page 4 This page has been left blank intentionally.
-
Page 5: Table Of Contents
Table of Contents Table of Contents Important safety precautions...............5 Safeguards..................5 Setting Up....................8 Accessories..................8 Installing the Stand................8 TV Front....................9 TV Rear...................10 Rear TV Connectors...............11 Connection Instructions..............12 Using the Remote Control................14 Installing the remote control batteries..........14 Remote control range..............14 The Remote Control Panel.............15 Quick starts..................16 Changing the TV Settings................18 Using the Channel Menu...............18... -
Page 6: Important Safety Precautions
Important safety precautions Safeguards This symbol alerts user about the presence of ATTENTION a dangerous voltage not isolated inside the product which can be sufficiently powerful to RISK OF SHOCK constitute a risk of electrocution. ELECTRIC This symbol alerts user about the presence of Do not open the back cover important operating instructions and In no case the user is allowed to operate inside the TV set. - Page 7 Important safety precautions Safeguards Please read the following safeguards for your TV and retain for future reference. Always follow all warnings and instructions marked on the television. 1. A note about safety and operating instructions Read and follow all safety and operating instructions, and retain them safely for future reference. 2.
- Page 8 Important safety precautions Safeguards 12.Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or power circuits, or where it can fall into such power lines or circuits. Where installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
-
Page 9: Setting Up
Setting Up Accessories/Installing the Stand Accessories list ALCD101 Batteries Remote Manual Book Installing the Stand 1. Place the TV faced down on a soft cloth or cushion on a table. 2. Attach the stand to the TV set as shown in the picture. 3. -
Page 10: Tv Front
Setting Up TV Front TV Front No. Component Component Description Press to turn the main power ON or OFF. POWER Switch Red indicates standby mode. Blue shows that the POWER Indicator unit is on.There will be no light when the power switch is in the off position. -
Page 11: Tv Rear
Setting Up TV Rear TV Rear HDMI1 HDMI3 VGA AUDIO IN SERVICE VIDEO VIDEO COMP2 COMP1... -
Page 12: Rear Tv Connectors
Setting Up Rear TV Connectors Connectors Brief Description Cables ANT 75Ω Connect an outdoor VHF/UHF antenna Yellow Video Connect a composite video cable and left-right audio cables from optical equipment. Video White (Audio connectors are shared with S-Video.) Input Yellow Video Connect a composite video cable and left-right audio cables to optical equipment for monitoring or recording video. -
Page 13: Connection Instructions
Setting Up Connection Instructions ■ Connecting an Aerial (For analogue and Digital signals) To view television channels correctly, a signal must be received by the set from the following source: -An outdoor VHF/UHF antenna ■ Connecting External A/V Devices -Connect a Video RCA or S-VIDEO cable to an appropriate external A/V device such as a VCR, DVD or Camcorder. - Page 14 Setting Up Connection Instructions ■ Connecting AUDIO -Connect RCA audio cables to “R -AUDIO - L” on the rear of your set and the other ends to corresponding audio in connectors on the Amplifier or DVD Home Theater. ■ Connecting USB Connector Devices -Connect a USB device for browsing photos and reading text files also used for servicing ■...
-
Page 15: Using The Remote Control
Using the remote Control Installing batteries Installing the remote control batteries 1. Open the battery cover on the back of the remote control. 2. Install two AAA size(1.5V) batteries. Match the “+” and “-” signs on the batteries to the signs on the battery compartment. -
Page 16: The Remote Control Panel
Using the Remote Control The Remote Control Panel The Remote Control Panel Buttons instructions(from up to down) (1) Remote sensing Window. (2) The White colour button:Indicates when the button is pushed. (3) D/A: Digital /Analog TV. (4) Power Standby: Power button(The red big button). (5) Source: Available source selection. -
Page 17: Quick Starts
Using the Remote Control Quick starts ■ Turning your TV on and off To turn your TV on: Connect the TV to an AC power outlet and an external antenna, then turn on the power via switch located below the front right hand side of unit. The power indicator will initially be red and then will change to blue. - Page 18 Using the Remote Control Quick starts ■ Selecting the picture mode ● To select a picture mode: Press the [Picture] button to select between 4 different pre-adjusted picture modes: Dynamic, Standard, Mild and User (configurable mode). The User mode automatically preserves your personal settings after adjusting brightness, colour and contrast etc.
-
Page 19: Changing The Tv Settings
Changing the TV Settings Using the Channel Menu ● Press [Menu] to open the main menu. Channel ● Press [◄/►] to select Channel, then press [▼/OK] to Auto Tuning enter the Channel menu. DTV Manual Tuning ATV Manual Tuning ● Press [▲/▼] to select an option. Program Edit ●... - Page 20 Changing the TV Settings Using the Channel Menu ■ Editing channels from memory After you scan for channels, you can delete a channel from memory if you want to skip the channel when you press [▲/▼]. You can still select the skipped channels using the number buttons. You can also rename the channels, lock or unlock the channels from memory.
-
Page 21: Using The Picture Menu
Changing the TV Settings Using the Picture Menu ● Press [Menu] to open the main menu. Picture ● Press [◄/►] to select Picture, then press [▼/OK] to Brightness enter the Picture menu. Contrast ● Press [▲/▼] to select an option. Color ●... -
Page 22: Using The Audio Menu
Changing the TV Settings Using the Sound Menu ● Press [Menu] to open the main menu. Sound ● Press [◄/►] to select Sound, then press [►/OK] to Balance Balance enter the Sound menu. Treble Treble ● Press [▲/▼] to select an option. Bass Bass ●... -
Page 23: Using The System Menu
Changing the TV Settings Using the Option Menu ● Press [Menu] to open the main menu. ● Press [◄/►] to select Option, then press [▼/OK] to Option enter the Option menu. Blue Screen ● Press [▲/▼] to select an option. Osd Settings ●... -
Page 24: Using The Lock Menu
Changing the TV Settings Using the Lock Menu ● Press [Menu] to open the main menu. Lock ● Press [◄/►] to select Lock, then press [▼/OK] to enter the Lock menu. Child Lock ● Press [▲/▼] to select an option. Set Password ●... -
Page 26: Using The Screen Menu
Changing the TV Settings Using the Screen Menu ● Press [Menu] to open the main menu. ● Press [◄/►] to select Screen, then press [▼/OK] to Screen enter the Screen menu. Image Position ● Press [▲/▼] to select an option. H Size ●... -
Page 27: Pc Setting
Changing the TV Settings PC Setting PC Setting Set the PC Software properly to match one of the below options. Supported VGA Modes: VGA____ (640×480 60Hz) SVGA___ (800×600 60Hz) XGA____ (1024×768 60Hz) SXGA___ (1280×1024 60Hz) Note: Your PC/Notebook may not be able to display some of these resolutions. Take Windows XP as an example, and the Windows system display setting is as illustrated: 1. -
Page 28: Using The Dmp Menu
Changing the TV Settings Using the DMP Menu ● Press [DMP] to open the DMP menu. ● Press [◄/►] to select PHOTO or TEXT, then press [OK] to enter PHOTO or TEXT file. PHOTO TEXT ● Press [▲/▼] to select an file. PHOTO ●... -
Page 29: Using The Teletext
Changing the TV Settings Using the Teletext Selecting teletext mode 1 Select the channel that is broadcasting the desired Teletext program. 2 Press [Text] to enable TELETEXT, press [Cancel] to exit TELETEXT. Note: All the operations below should be under the Teletext mode except TIME operation. You can directly input your desired page number by pressing the [0~9] buttons. -
Page 30: Appendix
Appendix Trouble shooting When there is something wrong with your TV, you can try turning off the TV and then restart it. You can also operate according to the following chart. If the problem still cannot be solved,please contact the professional technicians. Remedy Symptom 1. -
Page 31: Specifications
10.5 Kg Weight withbase 10.2 Kg 12Kg Environmental Temperature 5˚C~35˚C Conditions Humidity : 20%-80%RH Humidity : 20%-80%RH Atmospheric pressure: 86kPa-106kPa Note: Hisense is committed to continued product improvement which may result in changes to specifications and appearance without previous notice. - Page 32 HL66V88 HL81V88 Http://www.hisense.com.au...
