Figure 1 / Figura 1
H
G
Figure 2 / Figura 2
J
Figure 3 / Figura 3
18w Easel Lamp
C75002
INS-14-0122
B
F
A
Figure 4 / Figura 4
Figure 5 / Figura 5
Figure 7 / Figura 7
English
CONGRATULATIONS!
You've purchased the finest in natural lighting technology
with your new OttLite
PRODUCT REGISTRATION FORM
Please complete the enclosed Product Registration Form
and return it today by mail, or register online by going to:
OttLite.com/warranty.
WARNING! To prevent electrical shock, make sure the lamp
is not plugged in until all assembly steps are complete.
LAMP ASSEMbLy
1. Remove lamp and accessories from packing and place
them on a flat steady surface (a table).
2. To attach the 18w Easel Lamp to your easel, position the
clamp (A) on a solid leg or brace of the easel, then turn
knob (G). Adjust movable clamp jaw (H) as needed.
See Figure 2.
3. For additional clamp support and security, push lever
(J) downward. NOTE: Be sure to release lever prior to
loosening the clamp. See Figure 3.
4. Insert pole base (C) into hole in clamp (A) as noted in
Figure 1. Make sure the pole base is flush with the clamp.
NOTE: In addition to flexing neck for light movement,
lamp can be easily removed and re-inserted into clamp
(A) at a different position.
5. Set the lamp upright and follow TUBE INSERTION/
REPLACMENT directions to insert the tube.
6. Plug the power cord into a standard 120v socket.
7. To turn the lamp ON or OFF, depress the pushbutton
switch (F). See Figure 4.
8. Position shade (D) as desired by flexing the neck (B).
To avoid lamp breakage DO NOT FORCE neck to bend
or twist.
9. See Figures 5, 6, and 7 for recommended placement of
Figure 6 / Figura 6
18w Easel Lamp. DO NOT position the 18w Easel Lamp
horizontally as shown in Figure 8.
CAUTION! IMPORTANT SAFETY INSTRUCTIONS:
THIS PORTABLE LAMP HAS A POLARIZED PLUG (ONE BLADE IS WIDER THAN THE OTHER) AS A FEATURE TO REDUCE THE RISK OF ELECTRIC
SHOCK. THIS PLUG WILL FIT IN A POLARIZED OUTLET ONLY ONE WAY. IF THE PLUG DOES NOT FIT FULLY IN THE OUTLET, REVERSE THE
PLUG. IF IT STILL DOES NOT FIT, CONTACT A QUALIFIED ELECTRICIAN. NEVER USE WITH AN EXTENSION CORD UNLESS PLUG CAN BE FULLY
INSERTED. DO NOT ALTER THE PLUG.
IF THE EXTERNAL FLEXIBLE CABLE OR CORD OF THIS LUMINAIRE IS DAMAGED, IT SHALL BE EXCLUSIVELY REPLACED BY THE
MANUFACTURER OR ITS SERVICE AGENT OR A SIMILAR QUALIFIED PERSON IN ORDER TO AVOID A HAZARD. INDOOR USE ONLY.
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Figure 8 / Figura 8 This product complies with Part 18 of FCC Rules, but may cause interference to radios, televisions, wireless telephones, and remote controls.
Avoid placing this product near these devices. If interference occurs, move the product away from the device or plug either into a different
outlet. Do not install this product near maritime safety equipment or other critical navigation or communication equipment operating between
0.45-30 MHz.
This Class B RFLD complies with Canadian ICES-005
ACDL126
TUbE INSERTION & REPLACEMENT
1. Make sure the lamp is not plugged into an electrical
® product. socket.
2. If the lamp has been in use, allow it to cool for
approximately 5 minutes before proceeding.
3. Set the lamp upright on the easel.
4. To install a tube (E) in the shade (D) socket, grasp the
tube securely with your hand. Lay the tube flat then push
the tube into the shade clip. Align the tube base and
pins with the socket and receptacles and push the tube
straight into the socket until it "snaps" into place.
DO NOT apply pressure on the glass end of the tube.
5. To remove a tube already installed in the lamp, grasp
the tube firmly in your hand and angle it slightly out of
the shade clip; using a slight side to side motion, pull it
straight out of the socket. Do not twist or turn the tube
while removing it from the socket.
Enjoy your OttLite 18w Easel Lamp!
Please note that in operation, OttLite tubes are not
dimmable.
This lighting system is designed for use with OttLite
type
products voids the warranty and may result in damage
to the lighting system.
18w Easel Lamp
®
tubes (Style Number PL18-B). Use of other
REV071814
