OttLite K94CP3 Quick Start Manual

DO NOT USE SHADE
IN THIS AREA
NO UTILICE LA
PANTALLA EN ESTA
AREA
NE PAS PLACER
L'ABAT-JOUR DANS
CETTE ZONE.
K94CP3 K97CP4

CAUTION! IMPORTANT SAFETY INSTRUCTIONS:

THIS PORTABLE LAMP HAS A POLARIZED PLUG (ONE BLADE IS WIDER THAN THE OTHER) AS A FEATURE TO REDUCE THE
RISK OF ELECTRIC SHOCK. THIS PLUG WILL FIT IN A POLARIZED OUTLET ONLY ONE WAY. IF THE PLUG DOES NOT FIT FULLY
IN THE OUTLET, REVERSE THE PLUG. IF IT STILL DOES NOT FIT, CONTACT A QUALIFIED ELECTRICIAN. NEVER USE WITH AN
EXTENSION CORD UNLESS PLUG CAN BE FULLY INSERTED. DO NOT ALTER THE PLUG.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
INS150172 REV052715
U
S
Q
R
L
M
N
B
FIGURE 1 / FIGURA 1
Usable area for shade
Area útil para la pantalla
Zone sécuritaire pour
l'abat-jour
A
ST-790
D
E
F
T
P
C
H
J
A
D
E
K
F
G
G
ENGLISH

CONGRATULATIONS!

CLAMP-ON USE

You've purchased the finest in natural lighting 1. Attach clamp (J) to table, shelf or other strong,
technology with your new OttLite ® product. solid surface. Secure the clamp (J) by turning
screw (K) clockwise by hand until clamp is fas-

PRODUCT REGISTRATION FORM

tened tightly.
Please complete the enclosed Product Registration
Form and return it today by mail, or register online 2. Insert the dowel (C) into the hole of the clamp (J).
by going to: www.OttLite.com/warranty.

STEP 3: MAGNIFIER AND CLIP ATTACHMENT

WARNING: To prevent electric shock, make ASSEMBLY
sure the lamp is not plugged in until all assem- 1. Unscrew the wing nut (L) from the bolt (M) by
bly steps are complete. turning counter-clockwise and remove from the clip
(N).

CAUTION: TIP HAZARD

DO NOT MOVE SHADE OR ACCESSORIES 2. Attach the clip (N) to the shaft (P).
outside of the shaded area as shown in Figure
1. Shade and accessories must be kept within 3. To secure the attachment to the lamp, insert
the shaded area and must align in the same the bolt (M) through the hole on the clip (N) and
forward-facing direction as the base. tighten wing nut (L) by turning clockwise.

LAMP ASSEMBLY

CAUTION: Risk of fire! Never place the magni-
Your 3-in-1 Craft Lamp can be used as a Floor fier attachment under direct sunlight.
lamp, Table lamp or Clamp-On lamp.

STEP 4: TUBE INSERTION/REPLACEMENT

FLOOR USE

1. Make sure the lamp is not plugged into an
1. Remove bolt (F), flat washer (D), lock washer
electrical socket.
(E) and wrench (G) from plastic bag marked
"Floor Lamp." 2. If the lamp has been in use, allow it to cool for
approximately five minutes before proceeding.
2. Firmly insert the stem (B) of the lamp into the
hole located in the base (A). 3. To install a tube (Q) in the socket, grasp the tube
firmly in your hand. Clip the tube into the shade
3. Insert the bolt (F) through the lock washer (E),
clip and push the tube straight into the socket until
then through the flat washer (D) and finally into the it "snaps" into place. Do not apply pressure to the
recessed hole in the bottom of the base (A), as glass end of the tube.
indicated in the diagram.
4. To remove a tube (Q) already installed in the
4. Using the enclosed wrench (G), tighten the lamp, grasp the tube firmly in your hand and angle
bolt (F) securely by turning in a clockwise direction. it slightly out of the shade clip approximately 15
degrees and pull it straight out of the socket. Do
5. Insert dowel (C) into the hole of the stem (B). not twist or turn the tube while removing it from
the socket.

TABLE USE

1. Remove bolt (F), flat washer (D), lock washer BE CAREFUL TO AVOID TUBE BREAKAGE
(E) and wrench (G) from plastic bag marked FROM HITTING THE TUBE ON THE SHADE END.
"Table Lamp."
5. Plug the lamp into a standard 120V outlet.
2. Insert base adapter (H) into base (A).
6. Turn lamp on or off by depressing switch (R).
3. With power cord aligned toward rear of base,
insert dowel (C) into base adaptor (H). NOTE: To adjust lamp, turn wing nut (S, T)
counter-clockwise to loosen. Adjust shade (U)
4. Insert the bolt (F) through the lock washer (E), to desired position and tighten nut screws (S,
then through the flat washer (D) and finally into the T) by turning clockwise.
recessed hole in the bottom of the base (A), as
indicated in the diagram. Please note that in operation, OttLite
not dimmable.
5. Using the enclosed wrench (G), tighten the bolt
Enjoy your OttLite
(F) securely by turning in a clockwise direction.
This lighting system is designed for use with
OttLite
of other products voids the warranty and may
result in damage to the lighting system.
CAUTION!
If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer or its service
agent or a similar qualified person in order to avoid a hazard. Indoor use only.
24W 3-in-1 Craft Lamp
tubes are
®
3-in-1 Craft Lamp!
®
type (style number PL24-C). Use
®
