OttLite T96G5R Quick Start Manual

D
E
A
B
F
13w Universal Craft Lamp
T96G5R 915PN3
INS110013 REV051011
ENGLISH
CONGRATULATIONS!
You've purchased the finest in natural
lighting technology with your new
OttLite ® product.

PRODUCT REGISTRATION FORM

Please complete the enclosed Product
Registration Form and return it today
by mail, or register online by going to:
www.OttLite.com/warranty.
WARNING: To prevent electric shock,
make sure the lamp is not plugged in
until all assembly steps are complete.

LAMP ASSEMBLY

Your Universal Craft Lamp is capable of
clamping to a table edge or sitting on a
flat surface in a free-standing position.

CLAMP USE

1. Loosely assemble lower clamp (B) as
shown in diagram using thumbscrew (C)
to hold the pieces together.
2. Sandwich the table between upper
and lower clamp pieces and tighten
thumbscrew until snug. Use care to not
over-tighten.
3. Plug the lamp into a standard 120V
outlet.
4. To turn the lamp on or off depress the
rocker switch located in the cord mount-
ed power box.

FREE-STANDING USE

1. Loosely assemble lower clamp (B), as
shown in diagram, using thumbscrew (C)
to hold the pieces together.
C
2. Place stand (A), as shown, between
upper and lower clamp pieces.
3. Tighten thumbscrew to snugly hold the
stand. Place lamp as desired.
4. Place back-stand (F) over the thumb-
screw (C). Back-stand should face the
opposite direction of stand (A).
CAUTION!
GX7903
If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer
or its service agent or a similar qualified person in order to avoid a hazard. Indoor use only.
Universal Craft Lamp
CAUTION! IMPORTANT SAFETY INSTRUCTIONS:
THIS PORTABLE LAMP HAS A POLARIZED PLUG (ONE BLADE IS WIDER THAN THE OTHER) AS A FEATURE TO REDUCE
5. Plug the lamp into a standard 120V
THE RISK OF ELECTRIC SHOCK. THIS PLUG WILL FIT IN A POLARIZED OUTLET ONLY ONE WAY. IF THE PLUG DOES
outlet.
NOT FIT FULLY IN THE OUTLET, REVERSE THE PLUG. IF IT STILL DOES NOT FIT, CONTACT A QUALIFIED ELECTRICIAN.
NEVER USE WITH AN EXTENSION CORD UNLESS PLUG CAN BE FULLY INSERTED. DO NOT ALTER THE PLUG.
6. To turn the lamp on or off, rotate the
wheel of the in-line switch.
CAUTION:

TUBE INSERTION/REPLACEMENT

1. Make sure the lamp is not plugged into
CAUTION:
an electrical socket.
INCHES OF AIR SPACE MUST BE PROVIDED ON ALL SIDES EXCEPT WHERE PLUGGED INTO AN ELECTRICAL OUTLET.
2. If the lamp has been in use, allow it
to cool approximately 5 minutes before
¡ PRECAUCIÓN! INSTRUCCIONES DE SEGURIDAD
proceeding.
IMPORTANTES:
3. Remove the shade (E) by pulling it
away from the lamp.
ESTA LÁMPARA PORTÁTIL TIENE UN ENCHUFE POLARIZADO (UNA DE SUS PATAS ES MÁS ANCHA QUE LA OTRA)
4. To install a tube in the socket, hold
COMO CARACTERISTICA PARA REDUCIR EL RIESGO DE UNA DESCARGA ELÉCTRICA. ESTE ENCHUFE ENCAJARÁ EN
the tube (D) firmly at the base and push
CUALQUIER TOMACORRIENTE POLARIZADO SOLO DE UNA MANERA. SI EL ENCHUFE NO CALZA COMPLETAMENTE
it straight into the socket until it "snaps"
EN EL TOMACORRIENTE DÉLE LA VUELTA. SI AÚN NO ENCAJA, PÓNGASE EN CONTACTO CON UN ELECTRICISTA
into place.
CALIFICADO. NUNCA UTILICE UNA EXTENSIÓN A NO SER QUE EL ENCHUFE PUEDA SER TOTALMENTE
5. To remove a tube already installed in
INSERTADO. NO ALTERE EL ENCHUFE.
the lamp, grasp it firmly in your hand and
PRECAUCIÓN:
pull it straight out of the socket. Do not
twist or turn the tube while removing it
ENCHUFE CON LA RANURA ANCHA, INSERTE TOTALMENTE.
from the socket.
6. Replace the shade by aligning the
PRECAUCIÓN:
shade guide notches with the grooves in
the lamp head (E); push shade firmly into
CORRECTAMENTE. DEBE PROVEERSE UN ESPACIO DE AIRE DE UN MÍNIMO DE 6" EN TODOS LOS LADOS,
lamp head. A "click" should be heard.
EXCEPTO DONDE ESTÁ CONECTADA A UN TOMACORRIENTE.
Please note that in operation, OttLite ®
tubes are not dimmable.
AVERTISSEMENT! IMPORTANTES DIRECTIVES DE
Enjoy your OttLite ® Universal Craft lamp!
SÉCURITÉ:
This lighting system is designed for
CETTE LAMPE PORTATIVE EST MUNIE D'UNE FICHE POLARISÉE (UNE LAME PLUS LARGE QUE L'AUTRE). CE
use with OttLite tubes type
® (style
DISPOSITIF DE SÉCURITÉ DIMINUE LE RISQUE DE CHOCS ÉLECTRIQUES PUISQUE LA FICHE NE S'INSÈRE DANS
number PL13-A). Use of other products
LA PRISE QUE D'UN SEUL CÔTÉ. SI ELLE N'ENTRE PAS DANS LA PRISE, INVERSEZ-LA. SI ELLE N'ENTRE
voids the warranty and may result in
damage to the lighting system.
TOUJOURS PAS, CONTACTEZ UN ÉLECTRICIEN QUALIFIÉ. N'UTILISEZ JAMAIS AVEC UNE RALLONGE SAUF SI
LA FICHE S'INSÈRE ENTIÈREMENT. NE MODIFIEZ PAS CE DISPOSITIF DE SÉCURITÉ.
For more information on purchasing
replacement tubes/bulbs please go to
AVERTISSEMENT:
www.OttLite.com/replacement13wtube
DANS LA GRANDE FENTE ET POUSSEZ JUSQU'AU BOUT.
AVERTISSEMENT:
CORRECTAMENTE. DEBE PROVEERSE UN ESPACIO DE AIRE DE UN MÍNIMO DE 6" EN TODOS LOS LADOS,
EXCEPTO DONDE ESTÁ CONECTADA A UN TOMACORRIENTE.
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
BALLAST REQUIRES PROPER VENTILATION FOR PROPER OPERATION. A MINIMUM OF 6
